ROL
|
Provides the interface to apply upper and lower bound constraints. More...
#include <ROL_BoundConstraint.hpp>
Public Member Functions | |
virtual | ~BoundConstraint () |
BoundConstraint (void) | |
BoundConstraint (const Vector< Real > &x) | |
virtual void | project (Vector< Real > &x) |
Project optimization variables onto the bounds. More... | |
virtual void | projectInterior (Vector< Real > &x) |
Project optimization variables into the interior of the feasible set. More... | |
virtual void | pruneUpperActive (Vector< Real > &v, const Vector< Real > &x, Real eps=Real(0)) |
Set variables to zero if they correspond to the upper \(\epsilon\)-active set. More... | |
virtual void | pruneUpperActive (Vector< Real > &v, const Vector< Real > &g, const Vector< Real > &x, Real xeps=Real(0), Real geps=Real(0)) |
Set variables to zero if they correspond to the upper \(\epsilon\)-binding set. More... | |
virtual void | pruneLowerActive (Vector< Real > &v, const Vector< Real > &x, Real eps=Real(0)) |
Set variables to zero if they correspond to the lower \(\epsilon\)-active set. More... | |
virtual void | pruneLowerActive (Vector< Real > &v, const Vector< Real > &g, const Vector< Real > &x, Real xeps=Real(0), Real geps=Real(0)) |
Set variables to zero if they correspond to the \(\epsilon\)-binding set. More... | |
virtual const Ptr< const Vector< Real > > | getLowerBound (void) const |
Return the ref count pointer to the lower bound vector. More... | |
virtual const Ptr< const Vector< Real > > | getUpperBound (void) const |
Return the ref count pointer to the upper bound vector. More... | |
virtual bool | isFeasible (const Vector< Real > &v) |
Check if the vector, v, is feasible. More... | |
virtual void | applyInverseScalingFunction (Vector< Real > &dv, const Vector< Real > &v, const Vector< Real > &x, const Vector< Real > &g) const |
Apply inverse scaling function. More... | |
virtual void | applyScalingFunctionJacobian (Vector< Real > &dv, const Vector< Real > &v, const Vector< Real > &x, const Vector< Real > &g) const |
Apply scaling function Jacobian. More... | |
void | activateLower (void) |
Turn on lower bound. More... | |
void | activateUpper (void) |
Turn on upper bound. More... | |
void | activate (void) |
Turn on bounds. More... | |
void | deactivateLower (void) |
Turn off lower bound. More... | |
void | deactivateUpper (void) |
Turn off upper bound. More... | |
void | deactivate (void) |
Turn off bounds. More... | |
bool | isLowerActivated (void) const |
Check if lower bound are on. More... | |
bool | isUpperActivated (void) const |
Check if upper bound are on. More... | |
bool | isActivated (void) const |
Check if bounds are on. More... | |
void | pruneActive (Vector< Real > &v, const Vector< Real > &x, Real eps=Real(0)) |
Set variables to zero if they correspond to the \(\epsilon\)-active set. More... | |
void | pruneActive (Vector< Real > &v, const Vector< Real > &g, const Vector< Real > &x, Real xeps=Real(0), Real geps=Real(0)) |
Set variables to zero if they correspond to the \(\epsilon\)-binding set. More... | |
void | pruneLowerInactive (Vector< Real > &v, const Vector< Real > &x, Real eps=Real(0)) |
Set variables to zero if they correspond to the \(\epsilon\)-inactive set. More... | |
void | pruneUpperInactive (Vector< Real > &v, const Vector< Real > &x, Real eps=Real(0)) |
Set variables to zero if they correspond to the \(\epsilon\)-inactive set. More... | |
void | pruneLowerInactive (Vector< Real > &v, const Vector< Real > &g, const Vector< Real > &x, Real xeps=Real(0), Real geps=Real(0)) |
Set variables to zero if they correspond to the \(\epsilon\)-nonbinding set. More... | |
void | pruneUpperInactive (Vector< Real > &v, const Vector< Real > &g, const Vector< Real > &x, Real xeps=Real(0), Real geps=Real(0)) |
Set variables to zero if they correspond to the \(\epsilon\)-nonbinding set. More... | |
void | pruneInactive (Vector< Real > &v, const Vector< Real > &x, Real eps=Real(0)) |
Set variables to zero if they correspond to the \(\epsilon\)-inactive set. More... | |
void | pruneInactive (Vector< Real > &v, const Vector< Real > &g, const Vector< Real > &x, Real xeps=Real(0), Real geps=Real(0)) |
Set variables to zero if they correspond to the \(\epsilon\)-nonbinding set. More... | |
void | computeProjectedGradient (Vector< Real > &g, const Vector< Real > &x) |
Compute projected gradient. More... | |
void | computeProjectedStep (Vector< Real > &v, const Vector< Real > &x) |
Compute projected step. More... | |
Protected Member Functions | |
Real | computeInf (const Vector< Real > &x) const |
Protected Attributes | |
Ptr< Vector< Real > > | lower_ |
Ptr< Vector< Real > > | upper_ |
Private Attributes | |
bool | Lactivated_ |
Flag that determines whether or not the lower bounds are being used. More... | |
bool | Uactivated_ |
Flag that determines whether or not the upper bounds are being used. More... | |
Provides the interface to apply upper and lower bound constraints.
ROL's bound constraint class is to designed to handle point wise bound constraints on optimization variables. That is, let \(\mathcal{X}\) be a Banach space of functions from \(\Xi\) into \(\mathbb{R}\) (for example, \(\Xi\subset\mathbb{R}^d\) for some positive integer \(d\) and \(\mathcal{X}=L^2(\Xi)\) or \(\Xi = \{1,\ldots,n\}\) and \(\mathcal{X}=\mathbb{R}^n\)). For any \(x\in\mathcal{X}\), we consider bounds of the form
\[ a(\xi) \le x(\xi) \le b(\xi) \quad \text{for almost every }\xi\in\Xi. \]
Here, \(a(\xi)\le b(\xi)\) for almost every \(\xi\in\Xi\) and \(a,b\in \mathcal{X}\).
Definition at line 39 of file ROL_BoundConstraint.hpp.
|
inlinevirtual |
Definition at line 52 of file ROL_BoundConstraint.hpp.
ROL::BoundConstraint< Real >::BoundConstraint | ( | void | ) |
Definition at line 23 of file ROL_BoundConstraint_Def.hpp.
ROL::BoundConstraint< Real >::BoundConstraint | ( | const Vector< Real > & | x | ) |
Definition at line 27 of file ROL_BoundConstraint_Def.hpp.
References ROL::Vector< Real >::clone(), ROL::BoundConstraint< Real >::computeInf(), ROL::BoundConstraint< Real >::lower_, and ROL::BoundConstraint< Real >::upper_.
|
protected |
Definition at line 16 of file ROL_BoundConstraint_Def.hpp.
References dim, and ROL::Vector< Real >::dimension().
Referenced by ROL::BoundConstraint< Real >::BoundConstraint().
|
virtual |
Project optimization variables onto the bounds.
This function implements the projection of \(x\) onto the bounds, i.e.,
\[ (P_{[a,b]}(x))(\xi) = \min\{b(\xi),\max\{a(\xi),x(\xi)\}\} \quad \text{for almost every }\xi\in\Xi. \]
[in,out] | x | is the optimization variable. |
Reimplemented in H1BoundConstraint< Real >, H1BoundConstraint< Real >, L2BoundConstraint< Real >, H1BoundConstraint< Real >, L2BoundConstraint< Real >, L2BoundConstraint< Real >, BoundConstraint_BurgersControl< Real >, ROL::RiskBoundConstraint< Real >, ROL::Bounds< Real >, ROL::BoundConstraint_Partitioned< Real >, ROL::BoundConstraint_SimOpt< Real >, ROL::SimulatedBoundConstraint< Real >, and ROL::StdBoundConstraint< Real >.
Definition at line 40 of file ROL_BoundConstraint_Def.hpp.
Referenced by ROL::LineSearchStep< Real >::compute(), ROL::PrimalDualActiveSetStep< Real >::compute(), ROL::PrimalDualActiveSetStep< Real >::computeCriticalityMeasure(), ROL::TrustRegionStep< Real >::computeCriticalityMeasure(), ROL::AugmentedLagrangianStep< Real >::computeGradient(), ROL::FletcherStep< Real >::computeProjGradientNorm(), ROL::LineSearchStep< Real >::GradDotStep(), ROL::Step< Real >::initialize(), ROL::TypeB::KelleySachsAlgorithm< Real >::initialize(), ROL::MoreauYosidaPenaltyStep< Real >::initialize(), ROL::AugmentedLagrangianStep< Real >::initialize(), ROL::PrimalDualActiveSetStep< Real >::initialize(), ROL::TrustRegionStep< Real >::initialize(), ROL::TypeB::KelleySachsAlgorithm< Real >::run(), ROL::TypeB::PrimalDualActiveSetAlgorithm< Real >::run(), ROL::ProjectedNewtonStep< Real >::update(), ROL::ProjectedSecantStep< Real >::update(), ROL::TrustRegion< Real >::update(), ROL::ProjectedNewtonKrylovStep< Real >::update(), ROL::InteriorPointStep< Real >::update(), and ROL::LineSearch< Real >::updateIterate().
|
virtual |
Project optimization variables into the interior of the feasible set.
This function implements the projection of \(x\) into the interior of the feasible set, i.e.,
\[ (\bar{P}_{[a,b]}(x))(\xi) \in (a(\xi),b(\xi)) \quad \text{for almost every }\xi\in\Xi. \]
[in,out] | x | is the optimization variable. |
Reimplemented in ROL::RiskBoundConstraint< Real >, ROL::BoundConstraint_Partitioned< Real >, ROL::BoundConstraint_SimOpt< Real >, ROL::Bounds< Real >, ROL::SimulatedBoundConstraint< Real >, and ROL::StdBoundConstraint< Real >.
Definition at line 47 of file ROL_BoundConstraint_Def.hpp.
Referenced by ROL::TypeB::InteriorPointAlgorithm< Real >::initialize(), ROL::TypeG::InteriorPointAlgorithm< Real >::initialize(), ROL::InteriorPointStep< Real >::initialize(), and ROL::TrustRegionStep< Real >::initialize().
|
virtual |
Set variables to zero if they correspond to the upper \(\epsilon\)-active set.
This function sets \(v(\xi)=0\) if \(\xi\in\mathcal{A}^+_\epsilon(x)\). Here, the upper \(\epsilon\)-active set is defined as
\[ \mathcal{A}^+_\epsilon(x) = \{\,\xi\in\Xi\,:\,x(\xi) \ge b(\xi)-\epsilon\,\}. \]
[out] | v | is the variable to be pruned. |
[in] | x | is the current optimization variable. |
[in] | eps | is the active-set tolerance \(\epsilon\). |
Reimplemented in H1BoundConstraint< Real >, H1BoundConstraint< Real >, L2BoundConstraint< Real >, H1BoundConstraint< Real >, L2BoundConstraint< Real >, L2BoundConstraint< Real >, BoundConstraint_BurgersControl< Real >, ROL::RiskBoundConstraint< Real >, ROL::BoundConstraint_SimOpt< Real >, ROL::BoundConstraint_Partitioned< Real >, ROL::Bounds< Real >, ROL::SimulatedBoundConstraint< Real >, and ROL::StdBoundConstraint< Real >.
Definition at line 54 of file ROL_BoundConstraint_Def.hpp.
Referenced by ROL::PrimalDualActiveSetStep< Real >::compute().
|
virtual |
Set variables to zero if they correspond to the upper \(\epsilon\)-binding set.
This function sets \(v(\xi)=0\) if \(\xi\in\mathcal{B}^+_\epsilon(x)\). Here, the upper \(\epsilon\)-binding set is defined as
\[ \mathcal{B}^+_\epsilon(x) = \{\,\xi\in\Xi\,:\,x(\xi) \ge b(\xi)-\epsilon_x,\; g(\xi) < -\epsilon_g \,\}. \]
[out] | v | is the variable to be pruned. |
[in] | g | is the negative search direction. |
[in] | x | is the current optimization variable. |
[in] | xeps | is the active-set tolerance \(\epsilon_x\). |
[in] | geps | is the binding-set tolerance \(\epsilon_g\). |
Reimplemented in H1BoundConstraint< Real >, H1BoundConstraint< Real >, L2BoundConstraint< Real >, H1BoundConstraint< Real >, L2BoundConstraint< Real >, L2BoundConstraint< Real >, BoundConstraint_BurgersControl< Real >, ROL::RiskBoundConstraint< Real >, ROL::BoundConstraint_SimOpt< Real >, ROL::BoundConstraint_Partitioned< Real >, ROL::Bounds< Real >, ROL::SimulatedBoundConstraint< Real >, and ROL::StdBoundConstraint< Real >.
Definition at line 61 of file ROL_BoundConstraint_Def.hpp.
|
virtual |
Set variables to zero if they correspond to the lower \(\epsilon\)-active set.
This function sets \(v(\xi)=0\) if \(\xi\in\mathcal{A}^-_\epsilon(x)\). Here, the lower \(\epsilon\)-active set is defined as
\[ \mathcal{A}^-_\epsilon(x) = \{\,\xi\in\Xi\,:\,x(\xi) \le a(\xi)+\epsilon\,\}. \]
[out] | v | is the variable to be pruned. |
[in] | x | is the current optimization variable. |
[in] | eps | is the active-set tolerance \(\epsilon\). |
Reimplemented in H1BoundConstraint< Real >, H1BoundConstraint< Real >, L2BoundConstraint< Real >, H1BoundConstraint< Real >, L2BoundConstraint< Real >, L2BoundConstraint< Real >, BoundConstraint_BurgersControl< Real >, ROL::RiskBoundConstraint< Real >, ROL::BoundConstraint_SimOpt< Real >, ROL::BoundConstraint_Partitioned< Real >, ROL::Bounds< Real >, ROL::SimulatedBoundConstraint< Real >, and ROL::StdBoundConstraint< Real >.
Definition at line 68 of file ROL_BoundConstraint_Def.hpp.
Referenced by ROL::PrimalDualActiveSetStep< Real >::compute().
|
virtual |
Set variables to zero if they correspond to the \(\epsilon\)-binding set.
This function sets \(v(\xi)=0\) if \(\xi\in\mathcal{B}^-_\epsilon(x)\). Here, the lower \(\epsilon\)-binding set is defined as
\[ \mathcal{B}^-_\epsilon(x) = \{\,\xi\in\Xi\,:\,x(\xi) \le a(\xi)+\epsilon,\; g(\xi) > 0 \,\}. \]
[out] | v | is the variable to be pruned. |
[in] | g | is the negative search direction. |
[in] | x | is the current optimization variable. |
[in] | xeps | is the active-set tolerance \(\epsilon_x\). |
[in] | geps | is the binding-set tolerance \(\epsilon_g\). |
Reimplemented in H1BoundConstraint< Real >, H1BoundConstraint< Real >, L2BoundConstraint< Real >, H1BoundConstraint< Real >, L2BoundConstraint< Real >, L2BoundConstraint< Real >, BoundConstraint_BurgersControl< Real >, ROL::RiskBoundConstraint< Real >, ROL::BoundConstraint_SimOpt< Real >, ROL::BoundConstraint_Partitioned< Real >, ROL::Bounds< Real >, ROL::SimulatedBoundConstraint< Real >, and ROL::StdBoundConstraint< Real >.
Definition at line 75 of file ROL_BoundConstraint_Def.hpp.
|
virtual |
Return the ref count pointer to the lower bound vector.
Reimplemented in H1BoundConstraint< Real >, H1BoundConstraint< Real >, L2BoundConstraint< Real >, H1BoundConstraint< Real >, L2BoundConstraint< Real >, L2BoundConstraint< Real >, ROL::RiskBoundConstraint< Real >, ROL::BoundConstraint_SimOpt< Real >, and ROL::SimulatedBoundConstraint< Real >.
Definition at line 82 of file ROL_BoundConstraint_Def.hpp.
Referenced by ROL::BoundConstraint_Partitioned< Real >::BoundConstraint_Partitioned(), ROL::PrimalDualActiveSetStep< Real >::compute(), ROL::LowerBoundToConstraint< Real >::LowerBoundToConstraint(), ROL::RandomizeFeasibleVector(), and ROL::TypeB::PrimalDualActiveSetAlgorithm< Real >::run().
|
virtual |
Return the ref count pointer to the upper bound vector.
Reimplemented in H1BoundConstraint< Real >, H1BoundConstraint< Real >, L2BoundConstraint< Real >, H1BoundConstraint< Real >, L2BoundConstraint< Real >, L2BoundConstraint< Real >, ROL::RiskBoundConstraint< Real >, ROL::BoundConstraint_SimOpt< Real >, and ROL::SimulatedBoundConstraint< Real >.
Definition at line 90 of file ROL_BoundConstraint_Def.hpp.
Referenced by ROL::BoundConstraint_Partitioned< Real >::BoundConstraint_Partitioned(), ROL::PrimalDualActiveSetStep< Real >::compute(), ROL::RandomizeFeasibleVector(), ROL::TypeB::PrimalDualActiveSetAlgorithm< Real >::run(), and ROL::UpperBoundToConstraint< Real >::UpperBoundToConstraint().
|
virtual |
Check if the vector, v, is feasible.
This function returns true if \(v = P_{[a,b]}(v)\).
[in] | v | is the vector to be checked. |
Reimplemented in H1BoundConstraint< Real >, H1BoundConstraint< Real >, L2BoundConstraint< Real >, H1BoundConstraint< Real >, L2BoundConstraint< Real >, L2BoundConstraint< Real >, BoundConstraint_BurgersControl< Real >, ROL::RiskBoundConstraint< Real >, ROL::BoundConstraint_SimOpt< Real >, ROL::BoundConstraint_Partitioned< Real >, ROL::Bounds< Real >, ROL::SimulatedBoundConstraint< Real >, and ROL::StdBoundConstraint< Real >.
Definition at line 98 of file ROL_BoundConstraint_Def.hpp.
References ROL::Vector< Real >::clone().
Referenced by ROL::TypeB::LSecantBAlgorithm< Real >::dpcg(), ROL::TypeB::PrimalDualActiveSetAlgorithm< Real >::run(), ROL::TrustRegion< Real >::update(), and ROL::PrimalDualActiveSetStep< Real >::update().
|
virtual |
Apply inverse scaling function.
This function applies the inverse scaling function \(d(x,g)\) to a vector \(v\), i.e., the output is \(\mathrm{diag}(d(x,g)^{-1})v\). The scaling function must satisfy: (i) \(d(x,g)_i = 0\) if \(x_i = a_i\) and \(g_i \ge 0\); (ii) \(d(x,g)_i = 0\) if \(x_i = b_i\) and \(g_i \le 0\); and (iii) \(d(x,g)_i > 0\) otherwise.
[out] | dv | is the inverse scaling function applied to v. |
[in] | v | is the vector being scaled. |
[in] | x | is the primal vector at which the scaling function is evaluated. |
[in] | g | is the dual vector at which the scaling function is evaluated. |
Reimplemented in ROL::RiskBoundConstraint< Real >, ROL::BoundConstraint_SimOpt< Real >, ROL::BoundConstraint_Partitioned< Real >, ROL::SimulatedBoundConstraint< Real >, ROL::Bounds< Real >, and ROL::StdBoundConstraint< Real >.
Definition at line 112 of file ROL_BoundConstraint_Def.hpp.
Referenced by ROL::TypeB::ColemanLiAlgorithm< Real >::applyC().
|
virtual |
Apply scaling function Jacobian.
This function applies the Jacobian of the scaling function \(d(x,g)\) to a vector \(v\). The output is \(\mathrm{diag}(d_x(x,g)g)v\). The scaling function must satisfy: (i) \(d(x,g)_i = 0\) if \(x_i = a_i\) and \(g_i \ge 0\); (ii) \(d(x,g)_i = 0\) if \(x_i = b_i\) and \(g_i \le 0\); and (iii) \(d(x,g)_i > 0\) otherwise.
[out] | dv | is the scaling function Jacobian applied to v. |
[in] | v | is the vector being scaled. |
[in] | x | is the primal vector at which the scaling function is evaluated. |
[in] | g | is the dual vector at which the scaling function is evaluated. |
Reimplemented in ROL::RiskBoundConstraint< Real >, ROL::BoundConstraint_SimOpt< Real >, ROL::BoundConstraint_Partitioned< Real >, ROL::SimulatedBoundConstraint< Real >, ROL::Bounds< Real >, and ROL::StdBoundConstraint< Real >.
Definition at line 117 of file ROL_BoundConstraint_Def.hpp.
Referenced by ROL::TypeB::ColemanLiAlgorithm< Real >::applyC().
void ROL::BoundConstraint< Real >::activateLower | ( | void | ) |
Turn on lower bound.
This function turns on lower bounds.
Definition at line 122 of file ROL_BoundConstraint_Def.hpp.
Referenced by ROL::Bounds< Real >::Bounds(), and ROL::StdBoundConstraint< Real >::StdBoundConstraint().
void ROL::BoundConstraint< Real >::activateUpper | ( | void | ) |
Turn on upper bound.
This function turns on upper bounds.
Definition at line 127 of file ROL_BoundConstraint_Def.hpp.
Referenced by ROL::Bounds< Real >::Bounds(), and ROL::StdBoundConstraint< Real >::StdBoundConstraint().
void ROL::BoundConstraint< Real >::activate | ( | void | ) |
Turn on bounds.
This function turns the bounds on.
Definition at line 132 of file ROL_BoundConstraint_Def.hpp.
Referenced by ROL::BoundConstraint_Partitioned< Real >::BoundConstraint_Partitioned(), ROL::RiskBoundConstraint< Real >::RiskBoundConstraint(), and ROL::StdBoundConstraint< Real >::StdBoundConstraint().
void ROL::BoundConstraint< Real >::deactivateLower | ( | void | ) |
Turn off lower bound.
This function turns the lower bounds off.
Definition at line 138 of file ROL_BoundConstraint_Def.hpp.
void ROL::BoundConstraint< Real >::deactivateUpper | ( | void | ) |
Turn off upper bound.
This function turns the upper bounds off.
Definition at line 143 of file ROL_BoundConstraint_Def.hpp.
void ROL::BoundConstraint< Real >::deactivate | ( | void | ) |
Turn off bounds.
This function turns the bounds off.
Definition at line 148 of file ROL_BoundConstraint_Def.hpp.
Referenced by ROL::BoundConstraint_Partitioned< Real >::BoundConstraint_Partitioned(), ROL::BoundConstraint_SimOpt< Real >::BoundConstraint_SimOpt(), ROL::RiskBoundConstraint< Real >::RiskBoundConstraint(), and ROL::Algorithm< Real >::run().
bool ROL::BoundConstraint< Real >::isLowerActivated | ( | void | ) | const |
Check if lower bound are on.
This function returns true if the lower bounds are turned on.
Definition at line 154 of file ROL_BoundConstraint_Def.hpp.
Referenced by ROL::BoundConstraint_Partitioned< Real >::BoundConstraint_Partitioned(), and ROL::ObjectiveFromBoundConstraint< Real >::ObjectiveFromBoundConstraint().
bool ROL::BoundConstraint< Real >::isUpperActivated | ( | void | ) | const |
Check if upper bound are on.
This function returns true if the upper bounds are turned on.
Definition at line 159 of file ROL_BoundConstraint_Def.hpp.
Referenced by ROL::BoundConstraint_Partitioned< Real >::BoundConstraint_Partitioned(), and ROL::ObjectiveFromBoundConstraint< Real >::ObjectiveFromBoundConstraint().
bool ROL::BoundConstraint< Real >::isActivated | ( | void | ) | const |
Check if bounds are on.
This function returns true if the bounds are turned on.
Definition at line 164 of file ROL_BoundConstraint_Def.hpp.
Referenced by ROL::BoundConstraint_Partitioned< Real >::applyInverseScalingFunction(), ROL::BoundConstraint_Partitioned< Real >::applyScalingFunctionJacobian(), ROL::BoundConstraint_Partitioned< Real >::BoundConstraint_Partitioned(), ROL::LineSearchStep< Real >::compute(), ROL::AugmentedLagrangianStep< Real >::compute(), ROL::TrustRegionStep< Real >::compute(), ROL::TrustRegionStep< Real >::computeCriticalityMeasure(), ROL::AugmentedLagrangianStep< Real >::computeGradient(), ROL::FletcherStep< Real >::computeProjGradientNorm(), ROL::LineSearchStep< Real >::GradDotStep(), ROL::Step< Real >::initialize(), ROL::FletcherStep< Real >::initialize(), ROL::LineSearchStep< Real >::initialize(), ROL::MoreauYosidaPenaltyStep< Real >::initialize(), ROL::AugmentedLagrangianStep< Real >::initialize(), ROL::TrustRegionStep< Real >::initialize(), ROL::BoundConstraint_Partitioned< Real >::isFeasible(), ROL::BoundConstraint_Partitioned< Real >::project(), ROL::BoundConstraint_Partitioned< Real >::projectInterior(), ROL::BoundConstraint_Partitioned< Real >::pruneLowerActive(), ROL::BoundConstraint_Partitioned< Real >::pruneUpperActive(), ROL::LineSearch< Real >::status(), ROL::TrustRegion< Real >::update(), ROL::TrustRegionStep< Real >::update(), and ROL::LineSearch< Real >::updateIterate().
void ROL::BoundConstraint< Real >::pruneActive | ( | Vector< Real > & | v, |
const Vector< Real > & | x, | ||
Real | eps = Real(0) |
||
) |
Set variables to zero if they correspond to the \(\epsilon\)-active set.
This function sets \(v(\xi)=0\) if \(\xi\in\mathcal{A}_\epsilon(x)\). Here, the \(\epsilon\)-active set is defined as
\[ \mathcal{A}_\epsilon(x) = \mathcal{A}^+_\epsilon(x)\cap\mathcal{A}^-_\epsilon(x). \]
[out] | v | is the variable to be pruned. |
[in] | x | is the current optimization variable. |
[in] | eps | is the active-set tolerance \(\epsilon\). |
Definition at line 169 of file ROL_BoundConstraint_Def.hpp.
Referenced by ROL::TypeB::KelleySachsAlgorithm< Real >::applyFreeHessian(), ROL::TypeB::LSecantBAlgorithm< Real >::applyFreeHessian(), ROL::TypeB::LinMoreAlgorithm< Real >::applyFreeHessian(), ROL::TypeB::KelleySachsAlgorithm< Real >::applyFreePrecond(), ROL::TypeB::LSecantBAlgorithm< Real >::applyFreePrecond(), ROL::TypeB::LinMoreAlgorithm< Real >::applyFreePrecond(), ROL::ProjectedNewtonStep< Real >::compute(), ROL::ProjectedSecantStep< Real >::compute(), ROL::PrimalDualActiveSetStep< Real >::compute(), ROL::LineSearchStep< Real >::GradDotStep(), ROL::TypeB::LSecantBAlgorithm< Real >::run(), ROL::TypeB::KelleySachsAlgorithm< Real >::run(), ROL::TypeB::LinMoreAlgorithm< Real >::run(), ROL::TypeB::PrimalDualActiveSetAlgorithm< Real >::run(), ROL::LineSearch< Real >::status(), and ROL::TrustRegion< Real >::update().
void ROL::BoundConstraint< Real >::pruneActive | ( | Vector< Real > & | v, |
const Vector< Real > & | g, | ||
const Vector< Real > & | x, | ||
Real | xeps = Real(0) , |
||
Real | geps = Real(0) |
||
) |
Set variables to zero if they correspond to the \(\epsilon\)-binding set.
This function sets \(v(\xi)=0\) if \(\xi\in\mathcal{B}_\epsilon(x)\). Here, the \(\epsilon\)-binding set is defined as
\[ \mathcal{B}^+_\epsilon(x) = \mathcal{B}^+_\epsilon(x)\cap\mathcal{B}^-_\epsilon(x). \]
[out] | v | is the variable to be pruned. |
[in] | g | is the negative search direction. |
[in] | x | is the current optimization variable. |
[in] | xeps | is the active-set tolerance \(\epsilon_x\). |
[in] | geps | is the binding-set tolerance \(\epsilon_g\). |
Definition at line 177 of file ROL_BoundConstraint_Def.hpp.
void ROL::BoundConstraint< Real >::pruneLowerInactive | ( | Vector< Real > & | v, |
const Vector< Real > & | x, | ||
Real | eps = Real(0) |
||
) |
Set variables to zero if they correspond to the \(\epsilon\)-inactive set.
This function sets \(v(\xi)=0\) if \(\xi\in\Xi\setminus\mathcal{A}_\epsilon(x)\). Here,
[out] | v | is the variable to be pruned. |
[in] | x | is the current optimization variable. |
[in] | eps | is the active-set tolerance \(\epsilon\). |
Definition at line 185 of file ROL_BoundConstraint_Def.hpp.
References ROL::Vector< Real >::axpy(), and ROL::Vector< Real >::clone().
Referenced by ROL::TypeB::PrimalDualActiveSetAlgorithm< Real >::run().
void ROL::BoundConstraint< Real >::pruneUpperInactive | ( | Vector< Real > & | v, |
const Vector< Real > & | x, | ||
Real | eps = Real(0) |
||
) |
Set variables to zero if they correspond to the \(\epsilon\)-inactive set.
This function sets \(v(\xi)=0\) if \(\xi\in\Xi\setminus\mathcal{A}_\epsilon(x)\). Here,
[out] | v | is the variable to be pruned. |
[in] | x | is the current optimization variable. |
[in] | eps | is the active-set tolerance \(\epsilon\). |
Definition at line 196 of file ROL_BoundConstraint_Def.hpp.
References ROL::Vector< Real >::axpy(), and ROL::Vector< Real >::clone().
Referenced by ROL::TypeB::PrimalDualActiveSetAlgorithm< Real >::run().
void ROL::BoundConstraint< Real >::pruneLowerInactive | ( | Vector< Real > & | v, |
const Vector< Real > & | g, | ||
const Vector< Real > & | x, | ||
Real | xeps = Real(0) , |
||
Real | geps = Real(0) |
||
) |
Set variables to zero if they correspond to the \(\epsilon\)-nonbinding set.
This function sets \(v(\xi)=0\) if \(\xi\in\Xi\setminus\mathcal{B}_\epsilon(x)\).
[out] | v | is the variable to be pruned. |
[in] | x | is the current optimization variable. |
[in] | g | is the negative search direction. |
[in] | xeps | is the active-set tolerance \(\epsilon_x\). |
[in] | geps | is the binding-set tolerance \(\epsilon_g\). |
Definition at line 207 of file ROL_BoundConstraint_Def.hpp.
References ROL::Vector< Real >::axpy(), and ROL::Vector< Real >::clone().
void ROL::BoundConstraint< Real >::pruneUpperInactive | ( | Vector< Real > & | v, |
const Vector< Real > & | g, | ||
const Vector< Real > & | x, | ||
Real | xeps = Real(0) , |
||
Real | geps = Real(0) |
||
) |
Set variables to zero if they correspond to the \(\epsilon\)-nonbinding set.
This function sets \(v(\xi)=0\) if \(\xi\in\Xi\setminus\mathcal{B}_\epsilon(x)\).
[out] | v | is the variable to be pruned. |
[in] | x | is the current optimization variable. |
[in] | g | is the negative search direction. |
[in] | xeps | is the active-set tolerance \(\epsilon_x\). |
[in] | geps | is the binding-set tolerance \(\epsilon_g\). |
Definition at line 218 of file ROL_BoundConstraint_Def.hpp.
References ROL::Vector< Real >::axpy(), and ROL::Vector< Real >::clone().
void ROL::BoundConstraint< Real >::pruneInactive | ( | Vector< Real > & | v, |
const Vector< Real > & | x, | ||
Real | eps = Real(0) |
||
) |
Set variables to zero if they correspond to the \(\epsilon\)-inactive set.
This function sets \(v(\xi)=0\) if \(\xi\in\Xi\setminus\mathcal{A}_\epsilon(x)\). Here,
[out] | v | is the variable to be pruned. |
[in] | x | is the current optimization variable. |
[in] | eps | is the active-set tolerance \(\epsilon\). |
Definition at line 229 of file ROL_BoundConstraint_Def.hpp.
References ROL::Vector< Real >::axpy(), and ROL::Vector< Real >::clone().
Referenced by ROL::TypeB::KelleySachsAlgorithm< Real >::applyFreeHessian(), ROL::TypeB::KelleySachsAlgorithm< Real >::applyFreePrecond(), ROL::ProjectedNewtonStep< Real >::compute(), ROL::ProjectedSecantStep< Real >::compute(), ROL::LineSearchStep< Real >::GradDotStep(), ROL::TypeB::PrimalDualActiveSetAlgorithm< Real >::run(), and ROL::LineSearch< Real >::status().
void ROL::BoundConstraint< Real >::pruneInactive | ( | Vector< Real > & | v, |
const Vector< Real > & | g, | ||
const Vector< Real > & | x, | ||
Real | xeps = Real(0) , |
||
Real | geps = Real(0) |
||
) |
Set variables to zero if they correspond to the \(\epsilon\)-nonbinding set.
This function sets \(v(\xi)=0\) if \(\xi\in\Xi\setminus\mathcal{B}_\epsilon(x)\).
[out] | v | is the variable to be pruned. |
[in] | x | is the current optimization variable. |
[in] | g | is the negative search direction. |
[in] | xeps | is the active-set tolerance \(\epsilon_x\). |
[in] | geps | is the binding-set tolerance \(\epsilon_g\). |
Definition at line 240 of file ROL_BoundConstraint_Def.hpp.
References ROL::Vector< Real >::axpy(), and ROL::Vector< Real >::clone().
void ROL::BoundConstraint< Real >::computeProjectedGradient | ( | Vector< Real > & | g, |
const Vector< Real > & | x | ||
) |
Compute projected gradient.
This function projects the gradient \(g\) onto the tangent cone.
[in,out] | g | is the gradient of the objective function at x. |
[in] | x | is the optimization variable |
Definition at line 251 of file ROL_BoundConstraint_Def.hpp.
References ROL::Vector< Real >::clone().
Referenced by ROL::TrustRegionStep< Real >::computeCriticalityMeasure(), ROL::ProjectedNewtonStep< Real >::update(), ROL::ProjectedSecantStep< Real >::update(), and ROL::ProjectedNewtonKrylovStep< Real >::update().
void ROL::BoundConstraint< Real >::computeProjectedStep | ( | Vector< Real > & | v, |
const Vector< Real > & | x | ||
) |
Compute projected step.
This function computes the projected step \(P_{[a,b]}(x+v) - x\).
[in,out] | v | is the step variable. |
[in] | x | is the optimization variable. |
Definition at line 260 of file ROL_BoundConstraint_Def.hpp.
References ROL::Vector< Real >::axpy(), and ROL::Vector< Real >::plus().
|
private |
Flag that determines whether or not the lower bounds are being used.
Definition at line 41 of file ROL_BoundConstraint.hpp.
|
private |
Flag that determines whether or not the upper bounds are being used.
Definition at line 42 of file ROL_BoundConstraint.hpp.
|
protected |
|
protected |
