Provides access for Zoltan2 to Xpetra::CrsGraph data. More...
#include <Zoltan2_XpetraCrsGraphAdapter.hpp>
Public Member Functions | |
| XpetraCrsGraphAdapter (const RCP< const User > &ingraph, int nVtxWeights=0, int nEdgeWeights=0) | |
| Constructor for graph with no weights or coordinates. More... | |
| void | setWeights (const scalar_t *val, int stride, int idx) |
| Provide a pointer to weights for the primary entity type. More... | |
| void | setWeightsDevice (typename Base::ConstWeightsDeviceView &val, int idx) |
| void | setWeightsHost (typename Base::ConstWeightsHostView &val, int idx) |
| void | setVertexWeights (const scalar_t *val, int stride, int idx) |
| Provide a pointer to vertex weights. More... | |
| void | setVertexWeightsDevice (typename Base::ConstWeightsDeviceView &val, int idx) |
| void | setVertexWeightsHost (typename Base::ConstWeightsHostView &val, int idx) |
| void | setWeightIsDegree (int idx) |
| Specify an index for which the weight should be the degree of the entity. More... | |
| void | setVertexWeightIsDegree (int idx) |
| Specify an index for which the vertex weight should be the degree of the vertex. More... | |
| void | setEdgeWeights (const scalar_t *val, int stride, int idx) |
| Provide a pointer to edge weights. More... | |
| void | setEdgeWeightsDevice (typename Base::ConstWeightsDeviceView &val, int idx) |
| void | setEdgeWeightsHost (typename Base::ConstWeightsHostView &val, int idx) |
| RCP< const xgraph_t > | getXpetraGraph () const |
| Access to Xpetra-wrapped user's graph. More... | |
| RCP< const User > | getUserGraph () const |
| Access to user's graph. More... | |
| size_t | getLocalNumVertices () const override |
| Returns the number of vertices on this process. More... | |
| void | getVertexIDsView (const gno_t *&ids) const override |
| size_t | getLocalNumEdges () const override |
| Returns the number of edges on this process. More... | |
| void | getEdgesView (const offset_t *&offsets, const gno_t *&adjIds) const override |
| int | getNumWeightsPerVertex () const override |
| Returns the number (0 or greater) of weights per vertex. More... | |
| void | getVertexWeightsView (const scalar_t *&weights, int &stride, int idx) const override |
| Provide a pointer to the vertex weights, if any. More... | |
| bool | useDegreeAsVertexWeight (int idx) const override |
| Indicate whether vertex weight with index idx should be the global degree of the vertex. More... | |
| int | getNumWeightsPerEdge () const override |
| Returns the number (0 or greater) of edge weights. More... | |
| void | getEdgeWeightsView (const scalar_t *&weights, int &stride, int idx) const override |
| Provide a pointer to the edge weights, if any. More... | |
| template<typename Adapter > | |
| void | applyPartitioningSolution (const User &in, User *&out, const PartitioningSolution< Adapter > &solution) const |
| template<typename Adapter > | |
| void | applyPartitioningSolution (const User &in, RCP< User > &out, const PartitioningSolution< Adapter > &solution) const |
 Public Member Functions inherited from Zoltan2::GraphAdapter< User, UserCoord > | |
| enum BaseAdapterType | adapterType () const override |
| Returns the type of adapter. More... | |
| virtual void | getVertexIDsView (const gno_t *&vertexIds) const =0 |
| Sets pointers to this process' graph entries. More... | |
| virtual void | getVertexIDsDeviceView (typename Base::ConstIdsDeviceView &vertexIds) const |
| Sets pointers to this process' graph entries. More... | |
| virtual void | getVertexIDsHostView (typename Base::ConstIdsHostView &vertexIds) const |
| Sets pointers to this process' graph entries. More... | |
| virtual void | getEdgesView (const offset_t *&offsets, const gno_t *&adjIds) const =0 |
| Gets adjacency lists for all vertices in a compressed sparse row (CSR) format. More... | |
| virtual void | getEdgesDeviceView (typename Base::ConstOffsetsDeviceView &offsets, typename Base::ConstIdsDeviceView &adjIds) const |
| Gets adjacency lists for all vertices in a compressed sparse row (CSR) format. More... | |
| virtual void | getEdgesHostView (typename Base::ConstOffsetsHostView &offsets, typename Base::ConstIdsHostView &adjIds) const |
| Gets adjacency lists for all vertices in a compressed sparse row (CSR) format. More... | |
| virtual void | getVertexWeightsDeviceView (typename Base::WeightsDeviceView1D &weights, int=0) const |
| Provide a device view of the vertex weights, if any. More... | |
| virtual void | getVertexWeightsDeviceView (typename Base::WeightsDeviceView &weights) const |
| Provide a device view of the vertex weights, if any. More... | |
| virtual void | getVertexWeightsHostView (typename Base::WeightsHostView1D &weights, int=0) const |
| Provide a host view of the vertex weights, if any. More... | |
| virtual void | getVertexWeightsHostView (typename Base::WeightsHostView &weights) const |
| Provide a host view of the vertex weights, if any. More... | |
| virtual void | getEdgeWeightsDeviceView (typename Base::WeightsDeviceView1D &weights, int=0) const |
| Provide a device view of the edge weights, if any. More... | |
| virtual void | getEdgeWeightsDeviceView (typename Base::WeightsDeviceView &weights) const |
| Provide a device view of the edge weights, if any. More... | |
| virtual void | getEdgeWeightsHostView (typename Base::WeightsHostView1D &weights, int=0) const |
| Provide a host view of the edge weights, if any. More... | |
| virtual void | getEdgeWeightsHostView (typename Base::WeightsHostView &weights) const |
| Provide a host view of the edge weights, if any. More... | |
| void | setCoordinateInput (VectorAdapter< UserCoord > *coordData) override |
| Allow user to provide additional data that contains coordinate info associated with the MatrixAdapter's primaryEntityType_. Associated data must have the same parallel distribution and ordering of entries as the primaryEntityType_. More... | |
| bool | coordinatesAvailable () const |
| Indicate whether coordinate information has been set for this MatrixAdapter. More... | |
| VectorAdapter< UserCoord > * | getCoordinateInput () const override |
| Obtain the coordinate data registered by the user. More... | |
| enum GraphEntityType | getPrimaryEntityType () const |
| Returns the entity to be partitioned, ordered, colored, etc. Valid values are GRAPH_VERTEX or GRAPH_EDGE. More... | |
| void | setPrimaryEntityType (const std::string &typestr) |
| Sets the primary entity type. Called by algorithm based on parameter value in parameter list from application. Also sets to adjacencyEntityType_ to something reasonable: opposite of primaryEntityType_. More... | |
| enum GraphEntityType | getAdjacencyEntityType () const |
| Returns the entity that describes adjacencies between the entities to be partitioned, ordered, colored, etc. Valid values are GRAPH_VERTEX or GRAPH_EDGE. More... | |
| void | setAdjacencyEntityType (const std::string &typestr) |
| Sets the adjacency entity type. Called by algorithm based on parameter value in parameter list from application. Also sets to primaryEntityType_ to something reasonable: opposite of adjacencyEntityType_. More... | |
| size_t | getLocalNumIDs () const override |
| Returns the number of objects on this process. More... | |
| void | getIDsView (const gno_t *&Ids) const override |
| Provide a pointer to this process' identifiers. More... | |
| void | getIDsDeviceView (typename Base::ConstIdsDeviceView &Ids) const override |
| void | getIDsHostView (typename Base::ConstIdsHostView &Ids) const override |
| int | getNumWeightsPerID () const override |
| Returns the number of weights per object. Number of weights per object should be zero or greater. If zero, then it is assumed that all objects are equally weighted. Default is zero weights per ID. More... | |
| void | getWeightsView (const scalar_t *&wgt, int &stride, int idx=0) const override |
| Provide pointer to a weight array with stride. More... | |
| void | getWeightsHostView (typename Base::WeightsHostView1D &hostWgts, int idx=0) const override |
| void | getWeightsHostView (typename Base::WeightsHostView &hostWgts) const override |
| void | getWeightsDeviceView (typename Base::WeightsDeviceView1D &deviceWgts, int idx=0) const override |
| void | getWeightsDeviceView (typename Base::WeightsDeviceView &deviceWgts) const override |
| bool | useDegreeAsWeight (int idx) const |
| Public Member Functions inherited from Zoltan2::BaseAdapter< User > | |
| virtual void | getIDsKokkosView (ConstIdsDeviceView &ids) const |
| Provide a Kokkos view to this process' identifiers. More... | |
| virtual void | getIDsHostView (ConstIdsHostView &hostIds) const |
| Provide a Kokkos view (Host side) to this process' identifiers. More... | |
| virtual void | getIDsDeviceView (ConstIdsDeviceView &deviceIds) const |
| Provide a Kokkos view (Device side) to this process' identifiers. More... | |
| virtual void | getWeightsKokkosView (Kokkos::View< scalar_t **, device_t > &wgt) const |
| Provide kokkos view of weights. More... | |
| virtual void | getWeightsHostView (WeightsHostView1D &hostWgts, int idx=0) const |
| Provide a Kokkos view (Host side) of the weights. More... | |
| virtual void | getWeightsHostView (WeightsHostView &hostWgts) const |
| Provide a Kokkos view (Host side) of the weights. More... | |
| virtual void | getWeightsDeviceView (WeightsDeviceView1D &deviceWgts, int idx=0) const |
| Provide a Kokkos view (Device side) of the weights. More... | |
| virtual void | getWeightsDeviceView (WeightsDeviceView &deviceWgts) const |
| Provide a Kokkos view (Device side) of the weights. More... | |
| virtual void | getPartsView (const part_t *&inputPart) const |
| Provide pointer to an array containing the input part assignment for each ID. The input part information may be used for re-partitioning to reduce data movement, or for mapping parts to processes. Adapters may return NULL for this pointer (the default behavior); if NULL is returned, algorithms will assume the rank. More... | |
| virtual void | getPartsHostView (Kokkos::View< part_t *, host_t > &inputPart) const |
| virtual void | getPartsDeviceView (Kokkos::View< part_t *, device_t > &inputPart) const |
| template<typename Adapter > | |
| void | applyPartitioningSolution (const User &in, User *&out, const PartitioningSolution< Adapter > &solution) const |
| Apply a PartitioningSolution to an input. More... | |
| Public Member Functions inherited from Zoltan2::BaseAdapterRoot | |
| virtual | ~BaseAdapterRoot ()=default |
Additional Inherited Members | |
| Public Types inherited from Zoltan2::BaseAdapter< User > | |
| using | lno_t = typename InputTraits< User >::lno_t |
| using | gno_t = typename InputTraits< User >::gno_t |
| using | scalar_t = typename InputTraits< User >::scalar_t |
| using | node_t = typename InputTraits< User >::node_t |
| using | part_t = typename InputTraits< User >::part_t |
| using | offset_t = typename InputTraits< User >::offset_t |
| using | host_t = typename Kokkos::HostSpace::memory_space |
| using | device_t = typename node_t::device_type |
| using | ConstIdsDeviceView = Kokkos::View< const gno_t *, device_t > |
| using | ConstIdsHostView = typename ConstIdsDeviceView::HostMirror |
| using | IdsDeviceView = Kokkos::View< gno_t *, device_t > |
| using | IdsHostView = typename IdsDeviceView::HostMirror |
| using | ConstOffsetsDeviceView = Kokkos::View< const offset_t *, device_t > |
| using | ConstOffsetsHostView = typename ConstOffsetsDeviceView::HostMirror |
| using | OffsetsDeviceView = Kokkos::View< offset_t *, device_t > |
| using | OffsetsHostView = typename OffsetsDeviceView::HostMirror |
| using | ConstScalarsDeviceView = Kokkos::View< const scalar_t *, device_t > |
| using | ConstScalarsHostView = typename ConstScalarsDeviceView::HostMirror |
| using | ScalarsDeviceView = Kokkos::View< scalar_t *, device_t > |
| using | ScalarsHostView = typename ScalarsDeviceView::HostMirror |
| using | ConstWeightsDeviceView1D = Kokkos::View< const scalar_t *, device_t > |
| using | ConstWeightsHostView1D = typename ConstWeightsDeviceView1D::HostMirror |
| using | WeightsDeviceView1D = Kokkos::View< scalar_t *, device_t > |
| using | WeightsHostView1D = typename WeightsDeviceView1D::HostMirror |
| using | ConstWeightsDeviceView = Kokkos::View< const scalar_t **, device_t > |
| using | ConstWeightsHostView = typename ConstWeightsDeviceView::HostMirror |
| using | WeightsDeviceView = Kokkos::View< scalar_t **, device_t > |
| using | WeightsHostView = typename WeightsDeviceView::HostMirror |
| Protected Member Functions inherited from Zoltan2::BaseAdapter< User > | |
| void | generateWeightFileOnly (const char *fileprefix, const Teuchos::Comm< int > &comm) const |
Provides access for Zoltan2 to Xpetra::CrsGraph data.
test for memory alloc failure when we resize a vector
we assume FillComplete has been called. Should we support objects that are not FillCompleted.
The template parameter is the user's input object:
The scalar_t type, representing use data such as matrix values, is used by Zoltan2 for weights, coordinates, part sizes and quality metrics. Some User types (like Tpetra::CrsMatrix) have an inherent scalar type, and some (like Tpetra::CrsGraph) do not. For such objects, the scalar type is set by Zoltan2 to float. If you wish to change it to double, set the second template parameter to double.
Definition at line 84 of file Zoltan2_XpetraCrsGraphAdapter.hpp.
| Zoltan2::XpetraCrsGraphAdapter< User, UserCoord >::XpetraCrsGraphAdapter | ( | const RCP< const User > & | ingraph, |
| int | nVtxWeights = 0, |
||
| int | nEdgeWeights = 0 |
||
| ) |
Constructor for graph with no weights or coordinates.
| ingraph | the Epetra_CrsGraph, Tpetra::CrsGraph or Xpetra::CrsGraph |
| numVtxWeights | the number of weights per vertex (default = 0) |
| numEdgeWeights | the number of weights per edge (default = 0) |
Most adapters do not have RCPs in their interface. This one does because the user is obviously a Trilinos user.
Definition at line 291 of file Zoltan2_XpetraCrsGraphAdapter.hpp.
| void Zoltan2::XpetraCrsGraphAdapter< User, UserCoord >::setWeights | ( | const scalar_t * | val, |
| int | stride, | ||
| int | idx | ||
| ) |
Provide a pointer to weights for the primary entity type.
| val | A pointer to the weights for index idx. |
| stride | A stride for the val array. If is k, then val[n * k] is the weight for the n th entity for index . |
| idx | A number from 0 to one less than weight idx specified in the constructor. |
The order of the weights should match the order that entities appear in the input data structure.
Definition at line 363 of file Zoltan2_XpetraCrsGraphAdapter.hpp.
|
inline |
Definition at line 127 of file Zoltan2_XpetraCrsGraphAdapter.hpp.
|
inline |
Definition at line 128 of file Zoltan2_XpetraCrsGraphAdapter.hpp.
| void Zoltan2::XpetraCrsGraphAdapter< User, UserCoord >::setVertexWeights | ( | const scalar_t * | val, |
| int | stride, | ||
| int | idx | ||
| ) |
Provide a pointer to vertex weights.
| val | A pointer to the weights for index idx. |
| stride | A stride for the val array. If is k, then val[n * k] is the weight for the n th vertex for index . |
| idx | A number from 0 to one less than number of vertex weights specified in the constructor. |
The order of the vertex weights should match the order that vertices appear in the input data structure.
Definition at line 374 of file Zoltan2_XpetraCrsGraphAdapter.hpp.
| void Zoltan2::XpetraCrsGraphAdapter< User, UserCoord >::setVertexWeightsDevice | ( | typename Base::ConstWeightsDeviceView & | val, |
| int | idx | ||
| ) |
| void Zoltan2::XpetraCrsGraphAdapter< User, UserCoord >::setVertexWeightsHost | ( | typename Base::ConstWeightsHostView & | val, |
| int | idx | ||
| ) |
| void Zoltan2::XpetraCrsGraphAdapter< User, UserCoord >::setWeightIsDegree | ( | int | idx | ) |
Specify an index for which the weight should be the degree of the entity.
| idx | Zoltan2 will use the entity's degree as the entity weight for index idx. |
Definition at line 394 of file Zoltan2_XpetraCrsGraphAdapter.hpp.
| void Zoltan2::XpetraCrsGraphAdapter< User, UserCoord >::setVertexWeightIsDegree | ( | int | idx | ) |
Specify an index for which the vertex weight should be the degree of the vertex.
| idx | Zoltan2 will use the vertex's degree as the vertex weight for index idx. |
Definition at line 410 of file Zoltan2_XpetraCrsGraphAdapter.hpp.
| void Zoltan2::XpetraCrsGraphAdapter< User, UserCoord >::setEdgeWeights | ( | const scalar_t * | val, |
| int | stride, | ||
| int | idx | ||
| ) |
Provide a pointer to edge weights.
| val | A pointer to the weights for index idx. |
| stride | A stride for the val array. If is k, then val[n * k] is the weight for the n th edge for index . |
| dim | A number from 0 to one less than the number of edge weights specified in the constructor. |
The order of the edge weights should follow the order that the the vertices and edges appear in the input data structure.
By vertex:
Then by vertex neighbor:
Definition at line 426 of file Zoltan2_XpetraCrsGraphAdapter.hpp.
| void Zoltan2::XpetraCrsGraphAdapter< User, UserCoord >::setEdgeWeightsDevice | ( | typename Base::ConstWeightsDeviceView & | val, |
| int | idx | ||
| ) |
| void Zoltan2::XpetraCrsGraphAdapter< User, UserCoord >::setEdgeWeightsHost | ( | typename Base::ConstWeightsHostView & | val, |
| int | idx | ||
| ) |
|
inline |
Access to Xpetra-wrapped user's graph.
Definition at line 191 of file Zoltan2_XpetraCrsGraphAdapter.hpp.
|
inline |
Access to user's graph.
Definition at line 195 of file Zoltan2_XpetraCrsGraphAdapter.hpp.
|
inlineoverridevirtual |
Returns the number of vertices on this process.
Implements Zoltan2::GraphAdapter< User, UserCoord >.
Definition at line 203 of file Zoltan2_XpetraCrsGraphAdapter.hpp.
|
inlineoverride |
Definition at line 205 of file Zoltan2_XpetraCrsGraphAdapter.hpp.
|
inlineoverridevirtual |
Returns the number of edges on this process.
Implements Zoltan2::GraphAdapter< User, UserCoord >.
Definition at line 212 of file Zoltan2_XpetraCrsGraphAdapter.hpp.
|
inlineoverride |
Definition at line 214 of file Zoltan2_XpetraCrsGraphAdapter.hpp.
|
inlineoverridevirtual |
Returns the number (0 or greater) of weights per vertex.
Reimplemented from Zoltan2::GraphAdapter< User, UserCoord >.
Definition at line 220 of file Zoltan2_XpetraCrsGraphAdapter.hpp.
|
inlineoverridevirtual |
Provide a pointer to the vertex weights, if any.
| weights | is the list of weights of the given index for the vertices returned in getVertexIDsView(). |
| stride | The k'th weight is located at weights[stride*k] |
| idx | ranges from zero to one less than getNumWeightsPerVertex(). |
Reimplemented from Zoltan2::GraphAdapter< User, UserCoord >.
Definition at line 222 of file Zoltan2_XpetraCrsGraphAdapter.hpp.
|
inlineoverridevirtual |
Indicate whether vertex weight with index idx should be the global degree of the vertex.
Reimplemented from Zoltan2::GraphAdapter< User, UserCoord >.
Definition at line 238 of file Zoltan2_XpetraCrsGraphAdapter.hpp.
|
inlineoverridevirtual |
Returns the number (0 or greater) of edge weights.
Reimplemented from Zoltan2::GraphAdapter< User, UserCoord >.
Definition at line 240 of file Zoltan2_XpetraCrsGraphAdapter.hpp.
|
inlineoverridevirtual |
Provide a pointer to the edge weights, if any.
| weights | is the list of weights of the given index for the edges returned in getEdgeView(). |
| stride | The k'th weight is located at weights[stride*k] |
| idx | ranges from zero to one less than getNumWeightsPerEdge(). |
Reimplemented from Zoltan2::GraphAdapter< User, UserCoord >.
Definition at line 242 of file Zoltan2_XpetraCrsGraphAdapter.hpp.
| void Zoltan2::XpetraCrsGraphAdapter< User, UserCoord >::applyPartitioningSolution | ( | const User & | in, |
| User *& | out, | ||
| const PartitioningSolution< Adapter > & | solution | ||
| ) | const |
Definition at line 447 of file Zoltan2_XpetraCrsGraphAdapter.hpp.
| void Zoltan2::XpetraCrsGraphAdapter< User, UserCoord >::applyPartitioningSolution | ( | const User & | in, |
| RCP< User > & | out, | ||
| const PartitioningSolution< Adapter > & | solution | ||
| ) | const |
Definition at line 471 of file Zoltan2_XpetraCrsGraphAdapter.hpp.
1.8.5
