This class represents a collection of global Identifiers and their associated weights, if any. More...
#include <Zoltan2_BasicKokkosIdentifierAdapter.hpp>
Public Types | |
| typedef InputTraits< User > ::scalar_t | scalar_t |
| typedef InputTraits< User >::lno_t | lno_t |
| typedef InputTraits< User >::gno_t | gno_t |
| typedef InputTraits< User >::part_t | part_t |
| typedef InputTraits< User >::node_t | node_t |
| typedef node_t::device_type | device_t |
| typedef User | user_t |
 Public Types inherited from Zoltan2::BaseAdapter< User > | |
| using | lno_t = typename InputTraits< User >::lno_t |
| using | gno_t = typename InputTraits< User >::gno_t |
| using | scalar_t = typename InputTraits< User >::scalar_t |
| using | node_t = typename InputTraits< User >::node_t |
| using | part_t = typename InputTraits< User >::part_t |
| using | offset_t = typename InputTraits< User >::offset_t |
| using | host_t = typename Kokkos::HostSpace::memory_space |
| using | device_t = typename node_t::device_type |
| using | ConstIdsDeviceView = Kokkos::View< const gno_t *, device_t > |
| using | ConstIdsHostView = typename ConstIdsDeviceView::HostMirror |
| using | IdsDeviceView = Kokkos::View< gno_t *, device_t > |
| using | IdsHostView = typename IdsDeviceView::HostMirror |
| using | ConstOffsetsDeviceView = Kokkos::View< const offset_t *, device_t > |
| using | ConstOffsetsHostView = typename ConstOffsetsDeviceView::HostMirror |
| using | OffsetsDeviceView = Kokkos::View< offset_t *, device_t > |
| using | OffsetsHostView = typename OffsetsDeviceView::HostMirror |
| using | ConstScalarsDeviceView = Kokkos::View< const scalar_t *, device_t > |
| using | ConstScalarsHostView = typename ConstScalarsDeviceView::HostMirror |
| using | ScalarsDeviceView = Kokkos::View< scalar_t *, device_t > |
| using | ScalarsHostView = typename ScalarsDeviceView::HostMirror |
| using | ConstWeightsDeviceView1D = Kokkos::View< const scalar_t *, device_t > |
| using | ConstWeightsHostView1D = typename ConstWeightsDeviceView1D::HostMirror |
| using | WeightsDeviceView1D = Kokkos::View< scalar_t *, device_t > |
| using | WeightsHostView1D = typename WeightsDeviceView1D::HostMirror |
| using | ConstWeightsDeviceView = Kokkos::View< const scalar_t **, device_t > |
| using | ConstWeightsHostView = typename ConstWeightsDeviceView::HostMirror |
| using | WeightsDeviceView = Kokkos::View< scalar_t **, device_t > |
| using | WeightsHostView = typename WeightsDeviceView::HostMirror |
Public Member Functions | |
| BasicKokkosIdentifierAdapter (Kokkos::View< gno_t *, device_t > &ids, Kokkos::View< scalar_t **, device_t > &weights) | |
| Constructor. More... | |
| size_t | getLocalNumIDs () const override |
| Returns the number of objects on this process. More... | |
| void | getIDsView (const gno_t *&ids) const override |
| Provide a pointer to this process' identifiers. More... | |
| void | getIDsKokkosView (Kokkos::View< const gno_t *, device_t > &ids) const override |
| int | getNumWeightsPerID () const override |
| Returns the number of weights per object. Number of weights per object should be zero or greater. If zero, then it is assumed that all objects are equally weighted. Default is zero weights per ID. More... | |
| void | getWeightsView (const scalar_t *&wgt, int &stride, int idx=0) const override |
| Provide pointer to a weight array with stride. More... | |
| void | getWeightsKokkosView (Kokkos::View< scalar_t **, device_t > &wgts) const override |
| Provide kokkos view of weights. More... | |
| Public Member Functions inherited from Zoltan2::IdentifierAdapter< User > | |
| enum BaseAdapterType | adapterType () const |
| Returns the type of adapter. More... | |
| Public Member Functions inherited from Zoltan2::BaseAdapter< User > | |
| virtual void | getIDsKokkosView (ConstIdsDeviceView &ids) const |
| Provide a Kokkos view to this process' identifiers. More... | |
| virtual void | getIDsHostView (ConstIdsHostView &hostIds) const |
| Provide a Kokkos view (Host side) to this process' identifiers. More... | |
| virtual void | getIDsDeviceView (ConstIdsDeviceView &deviceIds) const |
| Provide a Kokkos view (Device side) to this process' identifiers. More... | |
| virtual void | getWeightsHostView (WeightsHostView1D &hostWgts, int idx=0) const |
| Provide a Kokkos view (Host side) of the weights. More... | |
| virtual void | getWeightsHostView (WeightsHostView &hostWgts) const |
| Provide a Kokkos view (Host side) of the weights. More... | |
| virtual void | getWeightsDeviceView (WeightsDeviceView1D &deviceWgts, int idx=0) const |
| Provide a Kokkos view (Device side) of the weights. More... | |
| virtual void | getWeightsDeviceView (WeightsDeviceView &deviceWgts) const |
| Provide a Kokkos view (Device side) of the weights. More... | |
| virtual void | getPartsView (const part_t *&inputPart) const |
| Provide pointer to an array containing the input part assignment for each ID. The input part information may be used for re-partitioning to reduce data movement, or for mapping parts to processes. Adapters may return NULL for this pointer (the default behavior); if NULL is returned, algorithms will assume the rank. More... | |
| virtual void | getPartsHostView (Kokkos::View< part_t *, host_t > &inputPart) const |
| virtual void | getPartsDeviceView (Kokkos::View< part_t *, device_t > &inputPart) const |
| template<typename Adapter > | |
| void | applyPartitioningSolution (const User &in, User *&out, const PartitioningSolution< Adapter > &solution) const |
| Apply a PartitioningSolution to an input. More... | |
| Public Member Functions inherited from Zoltan2::BaseAdapterRoot | |
| virtual | ~BaseAdapterRoot ()=default |
Additional Inherited Members | |
| Protected Member Functions inherited from Zoltan2::BaseAdapter< User > | |
| void | generateWeightFileOnly (const char *fileprefix, const Teuchos::Comm< int > &comm) const |
This class represents a collection of global Identifiers and their associated weights, if any.
The user supplies the identifiers and weights by way of pointers to arrays.
The template parameter (User) is a C++ class type which provides the actual data types with which the Zoltan2 library will be compiled, through a Traits mechanism. User may be the actual class used by application to represent coordinates, or it may be the empty helper class BasicUserTypes with which a Zoltan2 user can easily supply the data types for the library.
The scalar_t type, representing use data such as matrix values, is used by Zoltan2 for weights, coordinates, part sizes and quality metrics. Some User types (like Tpetra::CrsMatrix) have an inherent scalar type, and some (like Tpetra::CrsGraph) do not. For such objects, the scalar type is set by Zoltan2 to float. If you wish to change it to double, set the second template parameter to double.
Definition at line 84 of file Zoltan2_BasicKokkosIdentifierAdapter.hpp.
| typedef InputTraits<User>::scalar_t Zoltan2::BasicKokkosIdentifierAdapter< User >::scalar_t |
Definition at line 87 of file Zoltan2_BasicKokkosIdentifierAdapter.hpp.
| typedef InputTraits<User>::lno_t Zoltan2::BasicKokkosIdentifierAdapter< User >::lno_t |
Definition at line 88 of file Zoltan2_BasicKokkosIdentifierAdapter.hpp.
| typedef InputTraits<User>::gno_t Zoltan2::BasicKokkosIdentifierAdapter< User >::gno_t |
Definition at line 89 of file Zoltan2_BasicKokkosIdentifierAdapter.hpp.
| typedef InputTraits<User>::part_t Zoltan2::BasicKokkosIdentifierAdapter< User >::part_t |
Definition at line 90 of file Zoltan2_BasicKokkosIdentifierAdapter.hpp.
| typedef InputTraits<User>::node_t Zoltan2::BasicKokkosIdentifierAdapter< User >::node_t |
Definition at line 91 of file Zoltan2_BasicKokkosIdentifierAdapter.hpp.
| typedef node_t::device_type Zoltan2::BasicKokkosIdentifierAdapter< User >::device_t |
Definition at line 92 of file Zoltan2_BasicKokkosIdentifierAdapter.hpp.
| typedef User Zoltan2::BasicKokkosIdentifierAdapter< User >::user_t |
Definition at line 93 of file Zoltan2_BasicKokkosIdentifierAdapter.hpp.
| Zoltan2::BasicKokkosIdentifierAdapter< User >::BasicKokkosIdentifierAdapter | ( | Kokkos::View< gno_t *, device_t > & | ids, |
| Kokkos::View< scalar_t **, device_t > & | weights | ||
| ) |
Constructor.
| ids | should point to a View of identifiers. |
| weights | a list of pointers to arrays of weights. The number of weights per identifier is assumed to be weights.extent(0). |
| weightStrides | a list of strides for the weights. The weight for weight index n for ids[k] should be found at weights[n][weightStrides[n] * k]. If weightStrides.size() is zero, it is assumed all strides are one. |
The values pointed to the arguments must remain valid for the lifetime of this Adapter.
Definition at line 156 of file Zoltan2_BasicKokkosIdentifierAdapter.hpp.
|
inlineoverridevirtual |
Returns the number of objects on this process.
Objects may be coordinates, graph vertices, matrix rows, etc. They are the objects to be partitioned, ordered, or colored.
Implements Zoltan2::BaseAdapterRoot.
Definition at line 116 of file Zoltan2_BasicKokkosIdentifierAdapter.hpp.
|
inlineoverridevirtual |
Provide a pointer to this process' identifiers.
| ids | will on return point to the list of the global Ids for this process. |
Reimplemented from Zoltan2::BaseAdapter< User >.
Definition at line 120 of file Zoltan2_BasicKokkosIdentifierAdapter.hpp.
|
inlineoverride |
Definition at line 125 of file Zoltan2_BasicKokkosIdentifierAdapter.hpp.
|
inlineoverridevirtual |
Returns the number of weights per object. Number of weights per object should be zero or greater. If zero, then it is assumed that all objects are equally weighted. Default is zero weights per ID.
Reimplemented from Zoltan2::BaseAdapterRoot.
Definition at line 129 of file Zoltan2_BasicKokkosIdentifierAdapter.hpp.
|
inlineoverridevirtual |
Provide pointer to a weight array with stride.
| wgt | on return a pointer to the weights for this idx |
| stride | on return, the value such that the nth weight should be found at wgt[n*stride] . |
| idx | the weight index, zero or greater This function or getWeightsKokkosView must be implemented in derived adapter if getNumWeightsPerID > 0. This function should not be called if getNumWeightsPerID is zero. |
Reimplemented from Zoltan2::BaseAdapter< User >.
Definition at line 133 of file Zoltan2_BasicKokkosIdentifierAdapter.hpp.
|
inlineoverridevirtual |
Provide kokkos view of weights.
| wgt | on return a Kokkos view of the weights for this idx This function or getWeightsView must be implemented in derived adapter if getNumWeightsPerID > 0. This function should not be called if getNumWeightsPerID is zero. |
Reimplemented from Zoltan2::BaseAdapter< User >.
Definition at line 142 of file Zoltan2_BasicKokkosIdentifierAdapter.hpp.
