Moore-Spence turning point solver strategy based on "Phipps" bordering which is the 5-solve modified turning point bordering algorithm that uses bordered linear solves. More...
#include <LOCA_TurningPoint_MooreSpence_PhippsBordering.H>
Protected Member Functions | |
| NOX::Abstract::Group::ReturnType | solveContiguous (Teuchos::ParameterList ¶ms, const NOX::Abstract::MultiVector &input_x, const NOX::Abstract::MultiVector &input_null, const NOX::Abstract::MultiVector::DenseMatrix &input_param, NOX::Abstract::MultiVector &result_x, NOX::Abstract::MultiVector &result_null, NOX::Abstract::MultiVector::DenseMatrix &result_param) const |
| Solves equations with contiguous arguments. | |
| NOX::Abstract::Group::ReturnType | solveTransposeContiguous (Teuchos::ParameterList ¶ms, const NOX::Abstract::MultiVector &input_x, const NOX::Abstract::MultiVector &input_null, const NOX::Abstract::MultiVector::DenseMatrix &input_param, NOX::Abstract::MultiVector &result_x, NOX::Abstract::MultiVector &result_null, NOX::Abstract::MultiVector::DenseMatrix &result_param) const |
| Solves equations with contiguous arguments. | |
Moore-Spence turning point solver strategy based on "Phipps" bordering which is the 5-solve modified turning point bordering algorithm that uses bordered linear solves.
This class solves the Moore-Spence turning point Newton equations:
![\[ \begin{bmatrix} J & 0 & f_p \\ (Jv)_x & J & (Jv)_p \\ 0 & \phi^T & 0 \end{bmatrix} \begin{bmatrix} X \\ Y \\ z \end{bmatrix} = \begin{bmatrix} F \\ G \\ h \end{bmatrix} \]](form_606.png)
via the following modified block elimination scheme:
![\[ \begin{split} \begin{bmatrix} J & u \\ v^T & 0 \end{bmatrix} \begin{bmatrix} A & B \\ a & b \end{bmatrix} &= \begin{bmatrix} F & f_p \\ 0 & 0 \end{bmatrix} \\ \begin{bmatrix} J & u \\ v^T & 0 \end{bmatrix} \begin{bmatrix} C & D & E\\ c & d & e \end{bmatrix} &= \begin{bmatrix} (Jv)_x A - G & (Jv)_x B - (Jv)_p & (Jv)_x v \\ 0 & 0 & 0 \end{bmatrix} \\ \begin{bmatrix} \sigma & 0 & b \\ e & \sigma & -d \\ -\phi^T E & \phi^T v & \phi^T D \end{bmatrix} \begin{bmatrix} \alpha \\ \beta \\ z \end{bmatrix} &= \begin{bmatrix} a \\ c \\ h + \phi^T C \end{bmatrix} \\ X &= A - B z + v \alpha \\ Y &= -C + d z - E \alpha + v \beta \end{split} \]](form_607.png)
where
and
. Each bordered solve is implemented by a LOCA::BorderedSolver::AbstractStrategy strategy object.
| LOCA::TurningPoint::MooreSpence::PhippsBordering::PhippsBordering | ( | const Teuchos::RCP< LOCA::GlobalData > & | global_data, |
| const Teuchos::RCP< LOCA::Parameter::SublistParser > & | topParams, | ||
| const Teuchos::RCP< Teuchos::ParameterList > & | solverParams | ||
| ) |
Constructor.
| global_data | [in] Global data object |
| topParams | [in] Parsed top-level parameter list |
| solverParams | [in] Bordered solver parameters. Instantiates a bordered solver for solving the bordeded systems described above. See LOCA::BorderedSolver::Factory for a description of available solvers. |
References borderedSolver, globalData, LOCA::GlobalData::locaFactory, and solverParams.
|
virtual |
Set blocks in extended linear system.
| group | [in] Underlying group representing J |
| tpGroup | [in] Turning point group representing the turning point equations. |
| nullVector | [in] Vector representing v |
| JnVector | [in] Vector representing Jv |
| dfdp | [in] Vector representing df/dp |
| dJndp | [in] Vector representing d(Jv)/dp |
Implements LOCA::TurningPoint::MooreSpence::SolverStrategy.
References NOX::DeepCopy, NOX::Abstract::MultiVector::norm(), Teuchos::rcp(), and NOX::Abstract::Vector::TwoNorm.
|
virtual |
Solves the extended system as defined above.
The params argument is the linear solver parameters.
Implements LOCA::TurningPoint::MooreSpence::SolverStrategy.
References NOX::Abstract::MultiVector::clone(), LOCA::TurningPoint::MooreSpence::ExtendedMultiVector::getNullMultiVec(), LOCA::Extended::MultiVector::getScalars(), LOCA::TurningPoint::MooreSpence::ExtendedMultiVector::getXMultiVec(), NOX::Abstract::MultiVector::init(), LOCA::Extended::MultiVector::numVectors(), NOX::Abstract::MultiVector::setBlock(), and NOX::Abstract::MultiVector::subView().
|
virtual |
Solves the transpose of the extended system as defined above.
The params argument is the linear solver parameters.
Reimplemented from LOCA::TurningPoint::MooreSpence::SolverStrategy.
References NOX::Abstract::MultiVector::clone(), LOCA::TurningPoint::MooreSpence::ExtendedMultiVector::getNullMultiVec(), LOCA::Extended::MultiVector::getScalars(), LOCA::TurningPoint::MooreSpence::ExtendedMultiVector::getXMultiVec(), NOX::Abstract::MultiVector::init(), NOX::Abstract::Vector::init(), LOCA::Extended::MultiVector::numVectors(), NOX::Abstract::MultiVector::setBlock(), NOX::Abstract::MultiVector::subView(), and NOX::Abstract::Vector::update().
