Algebraic permutation strategy. More...
#include <MueLu_AlgebraicPermutationStrategy_fwd.hpp>
build permutation methods. | |
void | BuildPermutation (const Teuchos::RCP< Matrix > &A, const Teuchos::RCP< const Map > &permRowMap, Level ¤tLevel, const FactoryBase *genFactory) const |
build permutation operators More... | |
Additional Inherited Members | |
Public Member Functions inherited from MueLu::BaseClass | |
virtual | ~BaseClass () |
Destructor. More... | |
Public Member Functions inherited from MueLu::VerboseObject | |
VerbLevel | GetVerbLevel () const |
Get the verbosity level. More... | |
void | SetVerbLevel (const VerbLevel verbLevel) |
Set the verbosity level of this object. More... | |
int | GetProcRankVerbose () const |
Get proc rank used for printing. Do not use this information for any other purpose. More... | |
int | SetProcRankVerbose (int procRank) const |
Set proc rank used for printing. More... | |
bool | IsPrint (MsgType type, int thisProcRankOnly=-1) const |
Find out whether we need to print out information for a specific message type. More... | |
Teuchos::FancyOStream & | GetOStream (MsgType type, int thisProcRankOnly=0) const |
Get an output stream for outputting the input message type. More... | |
Teuchos::FancyOStream & | GetBlackHole () const |
VerboseObject () | |
virtual | ~VerboseObject () |
Destructor. More... | |
Public Member Functions inherited from Teuchos::VerboseObject< VerboseObject > | |
VerboseObject (const EVerbosityLevel verbLevel=VERB_DEFAULT, const RCP< FancyOStream > &oStream=Teuchos::null) | |
virtual const VerboseObject & | setVerbLevel (const EVerbosityLevel verbLevel) const |
virtual const VerboseObject & | setOverridingVerbLevel (const EVerbosityLevel verbLevel) const |
virtual EVerbosityLevel | getVerbLevel () const |
TEUCHOSPARAMETERLIST_LIB_DLL_EXPORT RCP< const ParameterList > | getValidVerboseObjectSublist () |
TEUCHOSPARAMETERLIST_LIB_DLL_EXPORT void | setupVerboseObjectSublist (ParameterList *paramList) |
TEUCHOSPARAMETERLIST_LIB_DLL_EXPORT void | readVerboseObjectSublist (ParameterList *paramList, RCP< FancyOStream > *oStream, EVerbosityLevel *verbLevel) |
void | readVerboseObjectSublist (ParameterList *paramList, VerboseObject< ObjectType > *verboseObject) |
Public Member Functions inherited from Teuchos::VerboseObjectBase | |
virtual | ~VerboseObjectBase () |
VerboseObjectBase (const RCP< FancyOStream > &oStream=Teuchos::null) | |
virtual const VerboseObjectBase & | setOStream (const RCP< FancyOStream > &oStream) const |
virtual const VerboseObjectBase & | setOverridingOStream (const RCP< FancyOStream > &oStream) const |
virtual VerboseObjectBase & | setLinePrefix (const std::string &linePrefix) |
virtual RCP< FancyOStream > | getOStream () const |
virtual RCP< FancyOStream > | getOverridingOStream () const |
virtual std::string | getLinePrefix () const |
virtual OSTab | getOSTab (const int tabs=1, const std::string &linePrefix="") const |
Public Member Functions inherited from MueLu::Describable | |
virtual | ~Describable () |
Destructor. More... | |
virtual std::string | ShortClassName () const |
Return the class name of the object, without template parameters and without namespace. More... | |
virtual void | describe (Teuchos::FancyOStream &out_arg, const VerbLevel verbLevel=Default) const |
virtual std::string | description () const |
Return a simple one-line description of this object. More... | |
void | describe (Teuchos::FancyOStream &out, const Teuchos::EVerbosityLevel verbLevel=Teuchos::Describable::verbLevel_default) const |
Print the object with some verbosity level to an FancyOStream object. More... | |
Public Member Functions inherited from Teuchos::Describable | |
void | describe (std::ostream &out, const EVerbosityLevel verbLevel=verbLevel_default) const |
LabeledObject () | |
virtual | ~LabeledObject () |
virtual void | setObjectLabel (const std::string &objectLabel) |
virtual std::string | getObjectLabel () const |
DescribableStreamManipulatorState | describe (const Describable &describable, const EVerbosityLevel verbLevel=Describable::verbLevel_default) |
std::ostream & | operator<< (std::ostream &os, const DescribableStreamManipulatorState &d) |
Static Public Member Functions inherited from MueLu::VerboseObject | |
static void | SetMueLuOStream (const Teuchos::RCP< Teuchos::FancyOStream > &mueluOStream) |
static Teuchos::RCP < Teuchos::FancyOStream > | GetMueLuOStream () |
static void | SetDefaultVerbLevel (const VerbLevel defaultVerbLevel) |
Set the default (global) verbosity level. More... | |
static VerbLevel | GetDefaultVerbLevel () |
Get the default (global) verbosity level. More... | |
Static Public Member Functions inherited from Teuchos::VerboseObject< VerboseObject > | |
static void | setDefaultVerbLevel (const EVerbosityLevel defaultVerbLevel) |
static EVerbosityLevel | getDefaultVerbLevel () |
Static Public Member Functions inherited from Teuchos::VerboseObjectBase | |
static void | setDefaultOStream (const RCP< FancyOStream > &defaultOStream) |
static RCP< FancyOStream > | getDefaultOStream () |
Static Public Attributes inherited from Teuchos::Describable | |
static const EVerbosityLevel | verbLevel_default |
Protected Member Functions inherited from Teuchos::VerboseObject< VerboseObject > | |
void | initializeVerboseObject (const EVerbosityLevel verbLevel=VERB_DEFAULT, const RCP< FancyOStream > &oStream=Teuchos::null) |
Protected Member Functions inherited from Teuchos::VerboseObjectBase | |
void | initializeVerboseObjectBase (const RCP< FancyOStream > &oStream=Teuchos::null) |
virtual void | informUpdatedVerbosityState () const |
Algebraic permutation strategy.
This class permutes columns of a input matrix A trying to make A a diagonal dominant matrix.
Definition at line 54 of file MueLu_AlgebraicPermutationStrategy_fwd.hpp.
void AlgebraicPermutationStrategy::BuildPermutation | ( | const Teuchos::RCP< Matrix > & | A, |
const Teuchos::RCP< const Map > & | permRowMap, | ||
Level & | currentLevel, | ||
const FactoryBase * | genFactory | ||
) | const |
build permutation operators
The following variables produced "A" : permuted and scaled A "permA" : permuted A without scaling "permP" : permutation opertor (should be identity) "permQT": transpose permutation operators "permScaling": scaling operator \param A: input matrix (input) \param permRowMap: Dof row map permutation shall be restricted on (input) \param currentLevel: only for output of variables \param genFactory: const pointer to generating (calling) PermutationFactory
TODO avoid this, not very elegant. Decide which variables have to be generated, give them back per reference to the PermutationFactory.
Definition at line 35 of file MueLu_AlgebraicPermutationStrategy_def.hpp.
