#include <Xpetra_TpetraOperator.hpp>
Private Attributes | |
| RCP< Tpetra::Operator< Scalar, LocalOrdinal, GlobalOrdinal, Node > > | op_ |
| The Tpetra::Operator which this class wraps. More... | |
| virtual const Teuchos::RCP < const Map< LocalOrdinal, GlobalOrdinal, Node > > | getDomainMap () const |
| The Map associated with the domain of this operator, which must be compatible with X.getMap(). More... | |
| virtual const Teuchos::RCP < const Map< LocalOrdinal, GlobalOrdinal, Node > > | getRangeMap () const |
| The Map associated with the range of this operator, which must be compatible with Y.getMap(). More... | |
| virtual void | apply (const Xpetra::MultiVector< Scalar, LocalOrdinal, GlobalOrdinal, Node > &X, Xpetra::MultiVector< Scalar, LocalOrdinal, GlobalOrdinal, Node > &Y, Teuchos::ETransp mode=Teuchos::NO_TRANS, Scalar alpha=Teuchos::ScalarTraits< Scalar >::one(), Scalar beta=Teuchos::ScalarTraits< Scalar >::zero()) const |
| Computes the operator-multivector application. More... | |
| virtual bool | hasTransposeApply () const |
| Whether this operator supports applying the transpose or conjugate transpose. More... | |
Overridden from Teuchos::Describable | |
| std::string | description () const |
| A simple one-line description of this object. More... | |
| void | describe (Teuchos::FancyOStream &out, const Teuchos::EVerbosityLevel verbLevel=Teuchos::Describable::verbLevel_default) const |
| Print the object with the given verbosity level to a FancyOStream. More... | |
Xpetra specific | |
| TpetraOperator () | |
| TpetraOperator (const Teuchos::RCP< Tpetra::Operator< Scalar, LocalOrdinal, GlobalOrdinal, Node > > &op) | |
| TpetraOperator constructor to wrap a Tpetra::Operator object. More... | |
| virtual RCP< Tpetra::Operator < Scalar, LocalOrdinal, GlobalOrdinal, Node > > | getOperator () |
| Gets the operator out. More... | |
| virtual RCP< const Tpetra::Operator< Scalar, LocalOrdinal, GlobalOrdinal, Node > > | getOperatorConst () const |
| Gets the operator out. More... | |
| void | residual (const Xpetra::MultiVector< Scalar, LocalOrdinal, GlobalOrdinal, Node > &X, const Xpetra::MultiVector< Scalar, LocalOrdinal, GlobalOrdinal, Node > &B, Xpetra::MultiVector< Scalar, LocalOrdinal, GlobalOrdinal, Node > &R) const |
| Compute a residual R = B - (*this) * X. More... | |
Additional Inherited Members | |
 Public Types inherited from Xpetra::Operator< Scalar, LocalOrdinal, GlobalOrdinal, Node > | |
| typedef Scalar | scalar_type |
| The type of the entries of the input and output multivectors. More... | |
| typedef LocalOrdinal | local_ordinal_type |
| The local index type. More... | |
| typedef GlobalOrdinal | global_ordinal_type |
| The global index type. More... | |
| typedef Node | node_type |
| The Kokkos Node type. More... | |
| Public Member Functions inherited from Xpetra::Operator< Scalar, LocalOrdinal, GlobalOrdinal, Node > | |
| virtual | ~Operator () |
| virtual void | removeEmptyProcessesInPlace (const RCP< const map_type > &) |
Definition at line 68 of file Xpetra_TpetraOperator.hpp.
|
inline |
Definition at line 126 of file Xpetra_TpetraOperator.hpp.
|
inline |
TpetraOperator constructor to wrap a Tpetra::Operator object.
Definition at line 129 of file Xpetra_TpetraOperator.hpp.
|
inlinevirtual |
The Map associated with the domain of this operator, which must be compatible with X.getMap().
Implements Xpetra::Operator< Scalar, LocalOrdinal, GlobalOrdinal, Node >.
Definition at line 73 of file Xpetra_TpetraOperator.hpp.
|
inlinevirtual |
The Map associated with the range of this operator, which must be compatible with Y.getMap().
Implements Xpetra::Operator< Scalar, LocalOrdinal, GlobalOrdinal, Node >.
Definition at line 79 of file Xpetra_TpetraOperator.hpp.
|
inlinevirtual |
Computes the operator-multivector application.
Loosely, performs \(Y = \alpha \cdot A^{\textrm{mode}} \cdot X + \beta \cdot Y\). However, the details of operation vary according to the values of alpha and beta. Specifically
beta == 0, apply() must overwrite Y, so that any values in Y (including NaNs) are ignored.alpha == 0, apply() may short-circuit the operator, so that any values in X (including NaNs) are ignored. Implements Xpetra::Operator< Scalar, LocalOrdinal, GlobalOrdinal, Node >.
Definition at line 91 of file Xpetra_TpetraOperator.hpp.
|
inlinevirtual |
Whether this operator supports applying the transpose or conjugate transpose.
Reimplemented from Xpetra::Operator< Scalar, LocalOrdinal, GlobalOrdinal, Node >.
Definition at line 100 of file Xpetra_TpetraOperator.hpp.
|
inline |
A simple one-line description of this object.
Definition at line 110 of file Xpetra_TpetraOperator.hpp.
|
inline |
Print the object with the given verbosity level to a FancyOStream.
Definition at line 116 of file Xpetra_TpetraOperator.hpp.
|
inlinevirtual |
Gets the operator out.
Definition at line 133 of file Xpetra_TpetraOperator.hpp.
|
inlinevirtual |
Gets the operator out.
Definition at line 136 of file Xpetra_TpetraOperator.hpp.
|
inlinevirtual |
Compute a residual R = B - (*this) * X.
Implements Xpetra::Operator< Scalar, LocalOrdinal, GlobalOrdinal, Node >.
Definition at line 139 of file Xpetra_TpetraOperator.hpp.
|
private |
The Tpetra::Operator which this class wraps.
Definition at line 149 of file Xpetra_TpetraOperator.hpp.
