Epetra_CrsGraph Class Reference

Epetra_CrsGraph: A class for constructing and using sparse compressed row graphs. More...

#include <Epetra_CrsGraph.h>

Inheritance diagram for Epetra_CrsGraph:
Inheritance graph
[legend]
Collaboration diagram for Epetra_CrsGraph:
Collaboration graph
[legend]

Public Member Functions

Epetra_CrsGraphoperator= (const Epetra_CrsGraph &Source)
 Assignment operator. More...

Constructors/Destructor
 Epetra_CrsGraph (Epetra_DataAccess CV, const Epetra_BlockMap &RowMap, const int *NumIndicesPerRow, bool StaticProfile=false)
 Epetra_CrsGraph constuctor with variable number of indices per row. More...

 Epetra_CrsGraph (Epetra_DataAccess CV, const Epetra_BlockMap &RowMap, int NumIndicesPerRow, bool StaticProfile=false)
 Epetra_CrsGraph constuctor with fixed number of indices per row. More...

 Epetra_CrsGraph (Epetra_DataAccess CV, const Epetra_BlockMap &RowMap, const Epetra_BlockMap &ColMap, const int *NumIndicesPerRow, bool StaticProfile=false)
 Epetra_CrsGraph constuctor with variable number of indices per row. More...

 Epetra_CrsGraph (Epetra_DataAccess CV, const Epetra_BlockMap &RowMap, const Epetra_BlockMap &ColMap, int NumIndicesPerRow, bool StaticProfile=false)
 Epetra_CrsGraph constuctor with fixed number of indices per row. More...

 Epetra_CrsGraph (const Epetra_CrsGraph &Graph)
 Copy constructor. More...

virtual ~Epetra_CrsGraph ()
 Epetra_CrsGraph Destructor.

Insertion/Removal methods
int InsertGlobalIndices (int GlobalRow, int NumIndices, int *Indices)
 Enter a list of elements in a specified global row of the graph. More...

int InsertGlobalIndices (long long GlobalRow, int NumIndices, long long *Indices)

int RemoveGlobalIndices (int GlobalRow, int NumIndices, int *Indices)
 Remove a list of elements from a specified global row of the graph. More...

int RemoveGlobalIndices (long long GlobalRow, int NumIndices, long long *Indices)

int RemoveGlobalIndices (long long Row)
 Remove all indices from a specified global row of the graph. More...

int InsertMyIndices (int LocalRow, int NumIndices, int *Indices)
 Enter a list of elements in a specified local row of the graph. More...

int RemoveMyIndices (int LocalRow, int NumIndices, int *Indices)
 Remove a list of elements from a specified local row of the graph. More...

int RemoveMyIndices (int Row)
 Remove all indices from a specified local row of the graph. More...

Transformation methods
int FillComplete ()
 Tranform to local index space. Perform other operations to allow optimal matrix operations. More...

int FillComplete (const Epetra_BlockMap &DomainMap, const Epetra_BlockMap &RangeMap)
 Transform to local index space using specified Domain/Range maps. Perform other operations to allow optimal matrix operations. More...

int OptimizeStorage ()
 Make consecutive row index sections contiguous, minimize internal storage used for constructing graph. More...

Extraction methods
int ExtractGlobalRowCopy (int GlobalRow, int LenOfIndices, int &NumIndices, int *Indices) const
 Extract a list of elements in a specified global row of the graph. Put into storage allocated by calling routine. More...

int ExtractGlobalRowCopy (long long GlobalRow, int LenOfIndices, int &NumIndices, long long *Indices) const

int ExtractMyRowCopy (int LocalRow, int LenOfIndices, int &NumIndices, int *Indices) const
 Extract a list of elements in a specified local row of the graph. Put into storage allocated by calling routine. More...

int ExtractGlobalRowView (int GlobalRow, int &NumIndices, int *&Indices) const
 Get a view of the elements in a specified global row of the graph. More...

int ExtractGlobalRowView (long long GlobalRow, int &NumIndices, long long *&Indices) const

int ExtractMyRowView (int LocalRow, int &NumIndices, int *&Indices) const
 Get a view of the elements in a specified local row of the graph. More...

Graph Properties Query Methods
bool Filled () const
 If FillComplete() has been called, this query returns true, otherwise it returns false.

bool StorageOptimized () const
 If OptimizeStorage() has been called, this query returns true, otherwise it returns false.

bool IndicesAreGlobal () const
 If column indices are in global range, this query returns true, otherwise it returns false.

bool IndicesAreLocal () const
 If column indices are in local range, this query returns true, otherwise it returns false.

bool LowerTriangular () const
 If graph is lower triangular in local index space, this query returns true, otherwise it returns false. More...

bool UpperTriangular () const
 If graph is upper triangular in local index space, this query returns true, otherwise it returns false. More...

bool NoDiagonal () const
 If graph has no diagonal entries in global index space, this query returns true, otherwise it returns false. More...

bool MyGlobalRow (int GID) const
 Returns true of GID is owned by the calling processor, otherwise it returns false.

bool MyGlobalRow (long long GID) const

bool HaveColMap () const
 Returns true if we have a well-defined ColMap, and returns false otherwise. More...

Attribute access functions
int NumMyRows () const
 Returns the number of matrix rows on this processor.

int NumGlobalRows () const
 Returns the number of matrix rows in global matrix.

long long NumGlobalRows64 () const

int NumMyCols () const
 Returns the number of entries in the set of column-indices that appear on this processor. More...

int NumGlobalCols () const
 Returns the number of matrix columns in global matrix. More...

long long NumGlobalCols64 () const

int NumGlobalNonzeros () const
 Returns the number of indices in the global graph. More...

long long NumGlobalNonzeros64 () const

int NumGlobalDiagonals () const
 Returns the number of diagonal entries in the global graph, based on global row/column index comparisons. More...

long long NumGlobalDiagonals64 () const

int NumMyDiagonals () const
 Returns the number of diagonal entries in the local graph, based on global row/column index comparisons. More...

int NumMyBlockRows () const
 Returns the number of block matrix rows on this processor.

int NumGlobalBlockRows () const
 Returns the number of Block matrix rows in global matrix.

long long NumGlobalBlockRows64 () const

int NumMyBlockCols () const
 Returns the number of Block matrix columns on this processor. More...

int NumGlobalBlockCols () const
 Returns the number of Block matrix columns in global matrix. More...

long long NumGlobalBlockCols64 () const

int NumMyBlockDiagonals () const
 Returns the number of Block diagonal entries in the local graph, based on global row/column index comparisons. More...

int NumGlobalBlockDiagonals () const
 Returns the number of Block diagonal entries in the global graph, based on global row/column index comparisons. More...

long long NumGlobalBlockDiagonals64 () const

int NumGlobalEntries () const
 Returns the number of entries in the global graph. More...

long long NumGlobalEntries64 () const

int NumMyEntries () const
 Returns the number of entries on this processor. More...

int MaxRowDim () const
 Returns the max row dimension of block entries on the processor. More...

int GlobalMaxRowDim () const
 Returns the max row dimension of block entries across all processors. More...

int MaxColDim () const
 Returns the max column dimension of block entries on the processor. More...

int GlobalMaxColDim () const
 Returns the max column dimension of block entries across all processors. More...

int NumMyNonzeros () const
 Returns the number of indices in the local graph. More...

int NumGlobalIndices (long long Row) const
 Returns the current number of nonzero entries in specified global row on this processor.

int NumAllocatedGlobalIndices (long long Row) const
 Returns the allocated number of nonzero entries in specified global row on this processor.

int MaxNumIndices () const
 Returns the maximum number of nonzero entries across all rows on this processor. More...

int GlobalMaxNumIndices () const
 Returns the maximun number of nonzero entries across all rows across all processors. More...

int MaxNumNonzeros () const
 Returns the maximum number of nonzero points across all rows on this processor. More...

int GlobalMaxNumNonzeros () const
 Returns the maximun number of nonzero points across all rows across all processors. More...

int NumMyIndices (int Row) const
 Returns the current number of nonzero entries in specified local row on this processor.

int NumAllocatedMyIndices (int Row) const
 Returns the allocated number of nonzero entries in specified local row on this processor.

int IndexBase () const
 Returns the index base for row and column indices for this graph. More...

long long IndexBase64 () const

const Epetra_BlockMapRowMap () const
 Returns the RowMap associated with this graph.

int ReplaceRowMap (const Epetra_BlockMap &newmap)

int ReplaceColMap (const Epetra_BlockMap &newmap)

int ReplaceDomainMapAndImporter (const Epetra_BlockMap &NewDomainMap, const Epetra_Import *NewImporter)
 Replaces the current DomainMap & Importer with the user-specified map object. More...

int RemoveEmptyProcessesInPlace (const Epetra_BlockMap *NewMap)
 Remove processes owning zero rows from the Maps and their communicator. More...

const Epetra_BlockMapColMap () const
 Returns the Column Map associated with this graph. More...

const Epetra_BlockMapDomainMap () const
 Returns the DomainMap associated with this graph. More...

const Epetra_BlockMapRangeMap () const
 Returns the RangeMap associated with this graph. More...

const Epetra_ImportImporter () const
 Returns the Importer associated with this graph.

const Epetra_ExportExporter () const
 Returns the Exporter associated with this graph.

const Epetra_CommComm () const
 Returns a pointer to the Epetra_Comm communicator associated with this graph.

Local/Global ID methods
int LRID (int GRID_in) const
 Returns the local row index for given global row index, returns -1 if no local row for this global row.

int LRID (long long GRID_in) const

int GRID (int LRID_in) const
 Returns the global row index for give local row index, returns IndexBase-1 if we don't have this local row.

long long GRID64 (int LRID_in) const

int LCID (int GCID_in) const
 Returns the local column index for given global column index, returns -1 if no local column for this global column. More...

int LCID (long long GCID_in) const

int GCID (int LCID_in) const
 Returns the global column index for give local column index, returns IndexBase-1 if we don't have this local column. More...

long long GCID64 (int LCID_in) const

bool MyGRID (int GRID_in) const
 Returns true if the GRID passed in belongs to the calling processor in this map, otherwise returns false.

bool MyGRID (long long GRID_in) const

bool MyLRID (int LRID_in) const
 Returns true if the LRID passed in belongs to the calling processor in this map, otherwise returns false.

bool MyGCID (int GCID_in) const
 Returns true if the GCID passed in belongs to the calling processor in this map, otherwise returns false. More...

bool MyGCID (long long GCID_in) const

bool MyLCID (int LCID_in) const
 Returns true if the LRID passed in belongs to the calling processor in this map, otherwise returns false. More...

Inlined Operator Methods
int * operator[] (int Loc)
 Inlined bracket operator for fast access to data. (Const and Non-const versions) More...

int * operator[] (int Loc) const

I/O Methods
virtual void Print (std::ostream &os) const
 Print method.

void PrintGraphData (std::ostream &os) const

void PrintGraphData (std::ostream &os, int level) const

Deprecated methods: These methods still work, but will be removed in a future version
const Epetra_BlockMapImportMap () const
 Use ColMap() instead.

int TransformToLocal ()
 Use FillComplete() instead.

int TransformToLocal (const Epetra_BlockMap *DomainMap, const Epetra_BlockMap *RangeMap)
 Use FillComplete(const Epetra_BlockMap& DomainMap, const Epetra_BlockMap& RangeMap) instead.

Expert Users and Developers Only
int ReferenceCount () const
 Returns the reference count of CrsGraphData. More...

const Epetra_CrsGraphDataDataPtr () const
 Returns a pointer to the CrsGraphData instance this CrsGraph uses. More...

Epetra_IntSerialDenseVectorExpertExtractIndexOffset ()
 Returns a reference to the Epetra_IntSerialDenseVector used to hold the local IndexOffsets (CRS rowptr) More...

Epetra_IntSerialDenseVectorExpertExtractIndices ()
 Returns a reference to the Epetra_IntSerialDenseVector used to hold the local All_Indices (CRS colind) More...

void SortGhostsAssociatedWithEachProcessor (bool Flag)
 Forces FillComplete() to locally order ghostnodes associated with each remote processor in ascending order. More...

- Public Member Functions inherited from Epetra_DistObject
 Epetra_DistObject (const Epetra_BlockMap &Map)
 Basic Epetra_DistObject constuctor. More...

 Epetra_DistObject (const Epetra_BlockMap &Map, const char *const Label)

 Epetra_DistObject (const Epetra_DistObject &Source)
 Epetra_DistObject copy constructor.

virtual ~Epetra_DistObject ()
 Epetra_DistObject destructor.

int Import (const Epetra_SrcDistObject &A, const Epetra_Import &Importer, Epetra_CombineMode CombineMode, const Epetra_OffsetIndex *Indexor=0)
 Imports an Epetra_DistObject using the Epetra_Import object. More...

int Import (const Epetra_SrcDistObject &A, const Epetra_Export &Exporter, Epetra_CombineMode CombineMode, const Epetra_OffsetIndex *Indexor=0)
 Imports an Epetra_DistObject using the Epetra_Export object. More...

int Export (const Epetra_SrcDistObject &A, const Epetra_Import &Importer, Epetra_CombineMode CombineMode, const Epetra_OffsetIndex *Indexor=0)
 Exports an Epetra_DistObject using the Epetra_Import object. More...

int Export (const Epetra_SrcDistObject &A, const Epetra_Export &Exporter, Epetra_CombineMode CombineMode, const Epetra_OffsetIndex *Indexor=0)
 Exports an Epetra_DistObject using the Epetra_Export object. More...

const Epetra_BlockMapMap () const
 Returns the address of the Epetra_BlockMap for this multi-vector.

const Epetra_CommComm () const
 Returns the address of the Epetra_Comm for this multi-vector.

bool DistributedGlobal () const
 Returns true if this multi-vector is distributed global, i.e., not local replicated.

- Public Member Functions inherited from Epetra_Object
 Epetra_Object (int TracebackModeIn=-1, bool set_label=true)
 Epetra_Object Constructor. More...

 Epetra_Object (const char *const Label, int TracebackModeIn=-1)
 Epetra_Object Constructor. More...

 Epetra_Object (const Epetra_Object &Object)
 Epetra_Object Copy Constructor. More...

virtual ~Epetra_Object ()
 Epetra_Object Destructor. More...

virtual int ReportError (const std::string Message, int ErrorCode) const
 Error reporting method.

virtual void SetLabel (const char *const Label)
 Epetra_Object Label definition using char *. More...

virtual const char * Label () const
 Epetra_Object Label access funtion. More...

- Public Member Functions inherited from Epetra_SrcDistObject
virtual ~Epetra_SrcDistObject ()
 Epetra_SrcDistObject destructor.


Protected Member Functions

int * All_Indices () const

int * IndexOffset () const

int * NumIndicesPerRow () const

int * NumAllocatedIndicesPerRow () const

int ** Indices () const

int * Indices (int LocalRow) const

template<typename int_type >
int_type ** TIndices () const

template<typename int_type >
int_type * TIndices (int LocalRow) const

bool IndicesAreContiguous () const

bool StaticProfile () const

bool GlobalConstantsComputed () const

bool FindGlobalIndexLoc (int LocalRow, int Index, int Start, int &Loc) const

bool FindGlobalIndexLoc (int NumIndices, const int *Indices, int Index, int Start, int &Loc) const

bool FindGlobalIndexLoc (int LocalRow, long long Index, int Start, int &Loc) const

bool FindGlobalIndexLoc (int NumIndices, const long long *Indices, long long Index, int Start, int &Loc) const

bool FindMyIndexLoc (int LocalRow, int Index, int Start, int &Loc) const

bool FindMyIndexLoc (int NumIndices, const int *Indices, int Index, int Start, int &Loc) const

int InsertIndices (int Row, int NumIndices, int *Indices)

int InsertIndicesIntoSorted (int Row, int NumIndices, int *Indices)

int InsertIndices (int Row, int NumIndices, long long *Indices)

int InsertIndicesIntoSorted (int Row, int NumIndices, long long *Indices)

int MakeIndicesLocal (const Epetra_BlockMap &DomainMap, const Epetra_BlockMap &RangeMap)

void SetIndicesAreLocal (bool Flag)

void SetIndicesAreGlobal (bool Flag)

void SetSorted (bool Flag)

int SortIndices ()
 Sort column indices, row-by-row, in ascending order. More...

bool Sorted () const
 If SortIndices() has been called, this query returns true, otherwise it returns false.

int RemoveRedundantIndices ()
 Removes any redundant column indices in the rows of the graph. More...

int DetermineTriangular ()

bool NoRedundancies () const
 If RemoveRedundantIndices() has been called, this query returns true, otherwise it returns false.

- Protected Member Functions inherited from Epetra_DistObject
virtual int DoTransfer (const Epetra_SrcDistObject &A, Epetra_CombineMode CombineMode, int NumSameIDs, int NumPermuteIDs, int NumRemoteIDs, int NumExportIDs, int *PermuteToLIDs, int *PermuteFromLIDs, int *RemoteLIDs, int *ExportLIDs, int &LenExports, char *&Exports, int &LenImports, char *&Imports, Epetra_Distributor &Distor, bool DoReverse, const Epetra_OffsetIndex *Indexor)
 Perform actual transfer (redistribution) of data across memory images, using Epetra_Distributor object.

- Protected Member Functions inherited from Epetra_Object
std::string toString (const int &x) const

std::string toString (const long long &x) const

std::string toString (const double &x) const


Friends

class Epetra_CrsMatrix

class Epetra_VbrMatrix

class Epetra_FECrsGraph

class Epetra_FECrsMatrix

class Epetra_FEVbrMatrix

class Epetra_OffsetIndex


Additional Inherited Members

- Static Public Member Functions inherited from Epetra_Object
static void SetTracebackMode (int TracebackModeValue)
 Set the value of the Epetra_Object error traceback report mode. More...

static int GetTracebackMode ()
 Get the value of the Epetra_Object error report mode.

static std::ostream & GetTracebackStream ()
 Get the output stream for error reporting.

- Static Public Attributes inherited from Epetra_Object
static int TracebackMode

- Protected Attributes inherited from Epetra_DistObject
Epetra_BlockMap Map_

const Epetra_CommComm_

char * Exports_

char * Imports_

int LenExports_

int LenImports_

int * Sizes_


Detailed Description

Epetra_CrsGraph: A class for constructing and using sparse compressed row graphs.

Epetra_CrsGraph enables the piecewise construction and use of sparse matrix graphs (the integer structure without
values) where entries are intended for row access.

Epetra_CrsGraph is an attribute of all Epetra row-based matrix classes, defining their nonzero structure and also
holding their Epetra_Map attributes.

Constructing Epetra_CrsGraph objects

Constructing Epetra_CrsGraph objects is a multi-step process. The basic steps are as follows:

  1. Create Epetra_CrsGraph instance, including some initial storage, via constructor. In addition to the copy constructor, Epetra_CrsGraph has four different constructors. All four of these constructors have an argument, StaticProfile, which by default is set to false. If it is set to true, then the profile (the number of indices per row as defined by NumIndicesPerRow) will be rigidly enforced. Although this takes away flexibility, it allows a single array to be allocated for all indices. This decreases memory fragmentation and improves performance across many operations. A more detailed discussion of the StaticProfile option is found below.
    1. User-provided row map, variable nonzero profile: This constructor is used to define the row distribution of the graph and specify a varying number of nonzero entries per row. It is best to use this constructor when the user will be inserting entries using global index values and wants every column index to be included in the graph. Note that in this case, the column map will be built for the user when FillComplete() is called. This constructor is also appropriate for when there is a large variation in the number of indices per row. If this is not the case, the next constructor may be more convenient to use.
    2. User-provided row map, fixed nonzero profile: This constructor is used to define the row distribution of the graph and specify a fixed number of nonzero entries per row. It is best to use this constructor when the user will be inserting entries using global index values and wants every column index to be included in the graph. Note that in this case, the column map will be built for the user when FillComplete() is called. This constructor is also appropriate for when there is little or no variation in the number of indices per row.
    3. User-provided row map, user-provided column map and variable nonzero profile: This constructor is used to define the row and column distribution of the graph, and specify a varying number of nonzero entries per row. It is best to use this constructor when the user will be inserting entries and already knows which columns of the matrix should be included on each processor. Note that in this case, the column map will not be built for the user when FillComplete() is called. Also, if the user attempts to insert a column index whose GID is not part of the column map on that process, the index will be discarded. This property can be used to "filter out" column entries that should be ignored. This constructor is also appropriate for when there is a large variation in the number of indices per row. If this is not the case, the next constructor may be more convenient to use.
    4. User-provided row map, user-provided column map and fixed nonzero profile: This constructor is used to define the row and column distribution of the graph, and specify a fixed number of nonzero entries per row. It is best to use this constructor when the user will be inserting entries and already knows which columns of the matrix should be included on each processor. Note that in this case, the column map will not be built for the user when FillComplete() is called. Also, if the user attempts to insert a column index whose GID is not part of the column map on that process, the index will be discarded. This constructor is also appropriate for when there is little or no variation in the number of indices per row.
  2. Enter row and column entry information via calls to the InsertGlobalIndices method.
  3. Complete construction via FillComplete call, which performs the following tasks:
    1. Transforms indices to local index space (after this, IndicesAreLocal()==true)
    2. Sorts column-indices within each row
    3. Compresses out any redundant indices within rows
    4. Computes global data such as num-nonzeros, maximum row-lengths, etc.
  4. (Optional) Optimize the graph storage via a call to OptimizeStorage.

Performance Enhancement Issues

The Epetra_CrsGraph class attempts to address four basic types of situations, depending on the user's primary concern:

  1. Simple, flexible construction over minimal memory use or control of column indices: In this case the user wants to provide only a row distribution of the graph and insert indices without worrying about memory allocation performance. This type of user is best served by the constructor that requires only a row map, and a fixed number of indices per row. In fact, setting NumIndicesPerRow=0 is probably the best option.
  2. Stronger control over memory allocation performance and use over flexibility and simplicity: In this case the user explicitly set StaticProfile to true and will provide values, either a single global int or an array of int's, for NumIndicesPerRow, such that the actual number of indices submitted to the graph will not exceed the estimates. Because we know that NumIndicesPerRow will not be exceeded, we can pre-allocate all of the storage for the graph as a single array. This is typically much more efficient.
  3. Explicit control over column indices: In this case the user prescribes the column map. Given the column map, any index that is submitted for entry into the graph will be included only if they are present in the list of GIDs for the column map on the processor that submits the index. This feature allows the user to define a filter such that only certain columns will be kept. The user also prescribes the local ordering via this technique, since the ordering of GIDs in the column map imposes the local ordering.
  4. Construction using local indices only: In some situations, users may want to build a graph using local index values only. In this case, the user must explicitly assign GIDs. This is done by prescribing the column map, in the same way as the previous situation.

Notes:

Epetra_Map attributes

Epetra_CrsGraph objects have four Epetra_Map attributes.

The Epetra_Map attributes can be obtained via these accessor methods:

It is important to note that while the row-map and the range-map are often the same, the column-map and the domain-map are almost never the same. The set of entries in a distributed column-map almost always form overlapping sets, with entries being associated with more than one processor. A domain-map, on the other hand, must be a 1-to-1 map, with entries being associated with only a single processor.

Global versus Local indices

After creation and before FillComplete() has been called, the column-indices of the graph are in the global space as received from the user. One of the tasks performed by FillComplete() is to transform the indices to a local index space. The query methods IndicesAreGlobal() and IndicesAreLocal() return true or false depending on whether this transformation has been performed or not.

Note the behavior of several graph methods:

Note that even after a graph is constructed, it is possible to add or remove entries. However, FillComplete must then be called again to restore the graph to a consistent state.

Constructor & Destructor Documentation

Epetra_CrsGraph::Epetra_CrsGraph ( Epetra_DataAccess  CV,
const Epetra_BlockMap RowMap,
const int *  NumIndicesPerRow,
bool  StaticProfile = false
)

Epetra_CrsGraph constuctor with variable number of indices per row.

Creates a Epetra_CrsGraph object and allocates storage.

Parameters
CV- (In) A Epetra_DataAccess enumerated type set to Copy or View.
RowMap- (In) An Epetra_BlockMap (or Epetra_Map or Epetra_LocalMap) listing the rows that this processor will contribute to.In
NumIndicesPerRow- (In) An integer array of length NumMyRows such that NumIndicesPerRow[i] indicates the (approximate if StaticProfile=false) number of entries in the ith row.
StaticProfile- (In) Optional argument that indicates whether or not NumIndicesPerRow should be interpreted as an exact count of nonzeros, or should be used as an approximation. By default this value is false, allowing the profile to be determined dynamically. If the user sets it to true, then the memory allocation for the Epetra_CrsGraph object will be done in one large block, saving on memory fragmentation and generally improving the performance of matrix multiplication and solve kernels.
Epetra_CrsGraph::Epetra_CrsGraph ( Epetra_DataAccess  CV,
const Epetra_BlockMap RowMap,
int  NumIndicesPerRow,
bool  StaticProfile = false
)

Epetra_CrsGraph constuctor with fixed number of indices per row.

Creates a Epetra_CrsGraph object and allocates storage.

Parameters
CV- (In) A Epetra_DataAccess enumerated type set to Copy or View.
RowMap- (In) An Epetra_BlockMap (or Epetra_Map or Epetra_LocalMap) listing the rows that this processor will contribute to.
NumIndicesPerRow- (In) An integer that indicates the (approximate if StaticProfile=false) number of entries in the each row. Note that it is possible to use 0 for this value and let fill occur during the insertion phase.
StaticProfile- (In) Optional argument that indicates whether or not NumIndicesPerRow should be interpreted as an exact count of nonzeros, or should be used as an approximation. By default this value is false, allowing the profile to be determined dynamically. If the user sets it to true, then the memory allocation for the Epetra_CrsGraph object will be done in one large block, saving on memory fragmentation and generally improving the performance of matrix multiplication and solve kernels.
Epetra_CrsGraph::Epetra_CrsGraph ( Epetra_DataAccess  CV,
const Epetra_BlockMap RowMap,
const Epetra_BlockMap ColMap,
const int *  NumIndicesPerRow,
bool  StaticProfile = false
)

Epetra_CrsGraph constuctor with variable number of indices per row.

Creates a Epetra_CrsGraph object and allocates storage.

Parameters
CV- (In) A Epetra_DataAccess enumerated type set to Copy or View.
RowMap- (In) An Epetra_BlockMap (or Epetra_Map or Epetra_LocalMap) listing the rows that this processor will contribute to.
ColMap- (In) An Epetra_BlockMap (or Epetra_Map or Epetra_LocalMap) listing the columns that this processor will contribute to.
NumIndicesPerRow- (In) An integer array of length NumMyRows such that NumIndicesPerRow[i] indicates the (approximate if StaticProfile=false) number of entries in the ith row.
StaticProfile- (In) Optional argument that indicates whether or not NumIndicesPerRow should be interpreted as an exact count of nonzeros, or should be used as an approximation. By default this value is false, allowing the profile to be determined dynamically. If the user sets it to true, then the memory allocation for the Epetra_CrsGraph object will be done in one large block, saving on memory fragmentation and generally improving the performance of matrix multiplication and solve kernels.
Epetra_CrsGraph::Epetra_CrsGraph ( Epetra_DataAccess  CV,
const Epetra_BlockMap RowMap,
const Epetra_BlockMap ColMap,
int  NumIndicesPerRow,
bool  StaticProfile = false
)

Epetra_CrsGraph constuctor with fixed number of indices per row.

Creates a Epetra_CrsGraph object and allocates storage.

Parameters
CV- (In) A Epetra_DataAccess enumerated type set to Copy or View.
RowMap- (In) An Epetra_BlockMap (or Epetra_Map or Epetra_LocalMap) listing the rows that this processor will contribute to.
ColMap- (In) An Epetra_BlockMap (or Epetra_Map or Epetra_LocalMap) listing the columns that this processor will contribute to.
InNumIndicesPerRow - An integer that indicates the (approximate if StaticProfile=false) number of entries in the each row. Note that it is possible to use 0 for this value and let fill occur during the insertion phase.
StaticProfile- (In) Optional argument that indicates whether or not NumIndicesPerRow should be interpreted as an exact count of nonzeros, or should be used as an approximation. By default this value is false, allowing the profile to be determined dynamically. If the user sets it to true, then the memory allocation for the Epetra_CrsGraph object will be done in one large block, saving on memory fragmentation and generally improving the performance of matrix multiplication and solve kernels.
Epetra_CrsGraph::Epetra_CrsGraph ( const Epetra_CrsGraph Graph)

Copy constructor.

This will create a Level 1 deep copy. This Graph will share ownership of the CrsGraphData object with the right hand side Graph.

Member Function Documentation

const Epetra_BlockMap& Epetra_CrsGraph::ColMap ( ) const
inline

Returns the Column Map associated with this graph.

Precondition
HaveColMap()==true
const Epetra_CrsGraphData* Epetra_CrsGraph::DataPtr ( ) const
inline

Returns a pointer to the CrsGraphData instance this CrsGraph uses.

(Intended for developer use only for testing purposes.)

const Epetra_BlockMap& Epetra_CrsGraph::DomainMap ( ) const
inline

Returns the DomainMap associated with this graph.

Precondition
Filled()==true
Epetra_IntSerialDenseVector& Epetra_CrsGraph::ExpertExtractIndexOffset ( )

Returns a reference to the Epetra_IntSerialDenseVector used to hold the local IndexOffsets (CRS rowptr)

Warning
This method is intended for experts only, its use may require user code modifications in future versions of Epetra.
Epetra_IntSerialDenseVector& Epetra_CrsGraph::ExpertExtractIndices ( )

Returns a reference to the Epetra_IntSerialDenseVector used to hold the local All_Indices (CRS colind)

Warning
This method is intended for experts only, its use may require user code modifications in future versions of Epetra.
int Epetra_CrsGraph::ExtractGlobalRowCopy ( int  GlobalRow,
int  LenOfIndices,
int &  NumIndices,
int *  Indices
) const

Extract a list of elements in a specified global row of the graph. Put into storage allocated by calling routine.

Parameters
Row- (In) Global row number to get indices.
LenOfIndices- (In) Length of Indices array.
NumIndices- (Out) Number of Indices.
Indices- (Out) Global column indices corresponding to values.
Returns
Integer error code, set to 0 if successful.
int Epetra_CrsGraph::ExtractGlobalRowView ( int  GlobalRow,
int &  NumIndices,
int *&  Indices
) const

Get a view of the elements in a specified global row of the graph.

This function requires that the graph not be completed (FillComplete() was not called).

Parameters
Row- (In) Global row number to get indices.
NumIndices- (Out) Number of Indices.
Indices- (Out) Global column indices corresponding to values.
Returns
Integer error code, set to 0 if successful. Returns -1 if invalid row. Returns -2 if graph is completed.
Precondition
IndicesAreLocal()==false
int Epetra_CrsGraph::ExtractMyRowCopy ( int  LocalRow,
int  LenOfIndices,
int &  NumIndices,
int *  Indices
) const

Extract a list of elements in a specified local row of the graph. Put into storage allocated by calling routine.

Parameters
Row- (In) Local row number to get indices.
LenOfIndices- (In) Length of Indices array.
NumIndices- (Out) Number of Indices.
Indices- (Out) Local column indices corresponding to values.
Returns
Integer error code, set to 0 if successful.
Precondition
IndicesAreLocal()==true
int Epetra_CrsGraph::ExtractMyRowView ( int  LocalRow,
int &  NumIndices,
int *&  Indices
) const

Get a view of the elements in a specified local row of the graph.

This function requires that the graph be completed FillComplete() was called).

Parameters
Row- (In) Local row number to get indices.
NumIndices- (Out) Number of Indices.
Indices- (Out) Column indices corresponding to values.
Returns
Integer error code, set to 0 if successful. Returns -1 if invalid row. Returns -2 if graph is not completed.
Precondition
IndicesAreLocal()==true
int Epetra_CrsGraph::FillComplete ( )

Tranform to local index space. Perform other operations to allow optimal matrix operations.

This overloading of the FillComplete method assumes that the domain-map and range-map both equal the row-map, and simply calls FillComplete(RowMap(), RowMap()).

Returns
Integer error code, set to 0 if successful. Returns 1 if data is shared (i.e., if the underlying graph-data object has a reference-count greater than 1).
Postcondition
IndicesAreLocal()==true, Filled()==true
int Epetra_CrsGraph::FillComplete ( const Epetra_BlockMap DomainMap,
const Epetra_BlockMap RangeMap
)

Transform to local index space using specified Domain/Range maps. Perform other operations to allow optimal matrix operations.

Performs this sequence of operations:

  1. Transform indices to local index space
  2. Sort column-indices within each row
  3. Compress out any redundant indices within rows
  4. Compute global data such as num-nonzeros, maximum row-lengths, etc.
Returns
Integer error code, set to 0 if successful. Returns 1 if data is shared (i.e., if the underlying graph-data object has a reference-count greater than 1).
Postcondition
IndicesAreLocal()==true, Filled()==true
int Epetra_CrsGraph::GCID ( int  LCID_in) const
inline

Returns the global column index for give local column index, returns IndexBase-1 if we don't have this local column.

Precondition
HaveColMap()==true (If HaveColMap()==false, returns -1)
int Epetra_CrsGraph::GlobalMaxColDim ( ) const
inline

Returns the max column dimension of block entries across all processors.

Precondition
Filled()==true
int Epetra_CrsGraph::GlobalMaxNumIndices ( ) const
inline

Returns the maximun number of nonzero entries across all rows across all processors.

Precondition
Filled()==true
int Epetra_CrsGraph::GlobalMaxNumNonzeros ( ) const
inline

Returns the maximun number of nonzero points across all rows across all processors.

This function returns the max over all processor of MaxNumNonzeros().

Precondition
Filled()==true
int Epetra_CrsGraph::GlobalMaxRowDim ( ) const
inline

Returns the max row dimension of block entries across all processors.

Precondition
Filled()==true
bool Epetra_CrsGraph::HaveColMap ( ) const
inline

Returns true if we have a well-defined ColMap, and returns false otherwise.

Precondition
We have a well-defined ColMap if a) a ColMap was passed in at construction, or b) the MakeColMap function has been called. (Calling either of the FillComplete functions will result in MakeColMap being called.)
int Epetra_CrsGraph::IndexBase ( ) const
inline

Returns the index base for row and column indices for this graph.

Index base for this map.

int Epetra_CrsGraph::InsertGlobalIndices ( int  GlobalRow,
int  NumIndices,
int *  Indices
)

Enter a list of elements in a specified global row of the graph.

Parameters
Row- (In) Global row number of indices.
NumIndices- (In) Number of Indices.
Indices- (In) Global column indices to insert.
Returns
Integer error code, set to 0 if successful. If the insertion requires that additional memory be allocated for the row, a positive error code of 1 is returned. If the graph is a 'View' mode graph, then a positive warning code of 2 will be returned if the specified row already exists. Returns 1 if underlying graph data is shared by multiple graph instances.
Precondition
IndicesAreGlobal()==true, StorageOptimized()==false
int Epetra_CrsGraph::InsertMyIndices ( int  LocalRow,
int  NumIndices,
int *  Indices
)

Enter a list of elements in a specified local row of the graph.

Parameters
Row- (In) Local row number of indices.
NumIndices- (In) Number of Indices.
Indices- (In) Local column indices to insert.
Returns
Integer error code, set to 0 if successful. If the insertion requires that additional memory be allocated for the row, a positive error code of 1 is returned. If one or more of the indices is ignored (due to not being contained in the column-map), then a positive warning code of 2 is returned. If the graph is a 'View' mode graph, then a positive warning code of 3 will be returned if the specified row already exists. Returns 1 if underlying graph data is shared by multiple graph instances.
Precondition
IndicesAreLocal()==true, StorageOptimized()==false
int Epetra_CrsGraph::LCID ( int  GCID_in) const
inline

Returns the local column index for given global column index, returns -1 if no local column for this global column.

Precondition
HaveColMap()==true (If HaveColMap()==false, returns -1)
bool Epetra_CrsGraph::LowerTriangular ( ) const
inline

If graph is lower triangular in local index space, this query returns true, otherwise it returns false.

Precondition
Filled()==true
int Epetra_CrsGraph::MaxColDim ( ) const
inline

Returns the max column dimension of block entries on the processor.

Precondition
Filled()==true
int Epetra_CrsGraph::MaxNumIndices ( ) const
inline

Returns the maximum number of nonzero entries across all rows on this processor.

Precondition
Filled()==true
int Epetra_CrsGraph::MaxNumNonzeros ( ) const
inline

Returns the maximum number of nonzero points across all rows on this processor.

For each entry in the graph, let i = the GRID of the entry and j = the CGID of the entry. Then the entry size is the product of the rowmap elementsize of i and the colmap elementsize of i. Let ki = sum of all entry sizes for the entries in the ith row. For example, if the ith block row had 5 block entries and the element size of each entry was 4-by-4, ki would be 80. Then this function returns the max over all ki for all row on this processor.

Precondition
Filled()==true
int Epetra_CrsGraph::MaxRowDim ( ) const
inline

Returns the max row dimension of block entries on the processor.

Precondition
Filled()==true
bool Epetra_CrsGraph::MyGCID ( int  GCID_in) const
inline

Returns true if the GCID passed in belongs to the calling processor in this map, otherwise returns false.

Precondition
HaveColMap()==true (If HaveColMap()==false, returns -1)
bool Epetra_CrsGraph::MyLCID ( int  LCID_in) const
inline

Returns true if the LRID passed in belongs to the calling processor in this map, otherwise returns false.

Precondition
HaveColMap()==true (If HaveColMap()==false, returns -1)
bool Epetra_CrsGraph::NoDiagonal ( ) const
inline

If graph has no diagonal entries in global index space, this query returns true, otherwise it returns false.

Precondition
Filled()==true
int Epetra_CrsGraph::NumGlobalBlockCols ( ) const
inline

Returns the number of Block matrix columns in global matrix.

Precondition
Filled()==true
int Epetra_CrsGraph::NumGlobalBlockDiagonals ( ) const
inline

Returns the number of Block diagonal entries in the global graph, based on global row/column index comparisons.

Precondition
Filled()==true
int Epetra_CrsGraph::NumGlobalCols ( ) const
inline

Returns the number of matrix columns in global matrix.

Precondition
Filled()==true
int Epetra_CrsGraph::NumGlobalDiagonals ( ) const
inline

Returns the number of diagonal entries in the global graph, based on global row/column index comparisons.

Precondition
Filled()==true
int Epetra_CrsGraph::NumGlobalEntries ( ) const
inline

Returns the number of entries in the global graph.

Precondition
Filled()==true
int Epetra_CrsGraph::NumGlobalNonzeros ( ) const
inline

Returns the number of indices in the global graph.

Note that if the graph's maps are defined such that some nonzeros appear on more than one processor, then those nonzeros will be counted more than once. If the user wishes to assemble a graph from overlapping data, they can use Epetra_FECrsGraph.

Precondition
Filled()==true
int Epetra_CrsGraph::NumMyBlockCols ( ) const
inline

Returns the number of Block matrix columns on this processor.

Precondition
Filled()==true
int Epetra_CrsGraph::NumMyBlockDiagonals ( ) const
inline

Returns the number of Block diagonal entries in the local graph, based on global row/column index comparisons.

Precondition
Filled()==true
int Epetra_CrsGraph::NumMyCols ( ) const
inline

Returns the number of entries in the set of column-indices that appear on this processor.

The set of column-indices that appear on this processor is the union of column-indices that appear in all local rows. The size of this set isn't available until FillComplete() has been called.

Precondition
Filled()==true
int Epetra_CrsGraph::NumMyDiagonals ( ) const
inline

Returns the number of diagonal entries in the local graph, based on global row/column index comparisons.

Precondition
Filled()==true
int Epetra_CrsGraph::NumMyEntries ( ) const
inline

Returns the number of entries on this processor.

Precondition
Filled()==true
int Epetra_CrsGraph::NumMyNonzeros ( ) const
inline

Returns the number of indices in the local graph.

Precondition
Filled()==true
Epetra_CrsGraph& Epetra_CrsGraph::operator= ( const Epetra_CrsGraph Source)

Assignment operator.

This will do a Level 1 deep copy. It will share ownership of the CrsGraphData with the right hand side Graph.

int* Epetra_CrsGraph::operator[] ( int  Loc)
inline

Inlined bracket operator for fast access to data. (Const and Non-const versions)

No error checking and dangerous for optimization purposes.

Parameters
Loc(In) - Local row.
Returns
reference to pointer to locally indexed Loc row in matrix.
int Epetra_CrsGraph::OptimizeStorage ( )

Make consecutive row index sections contiguous, minimize internal storage used for constructing graph.

After construction and during initialization (when indices are being added via InsertGlobalIndices() etc.), the column- indices for each row are held in a separate piece of allocated memory. This method moves the column-indices for all rows into one large contiguous array and eliminates internal storage that is not needed after graph construction. Calling this method can have a significant impact on memory costs and machine performance.

If this object was constructed in View mode then this method can't make non-contiguous indices contiguous and will return a warning code of 1 if the viewed data isn't already contiguous.

Returns
Integer error code, set to 0 if successful.
Precondition
Filled()==true.
If CV=View when the graph was constructed, then this method will be effective only if the indices of the graph were already contiguous. In this case, the indices are left untouched and internal storage for the graph is minimized.
Postcondition
StorageOptimized()==true, if successful
const Epetra_BlockMap& Epetra_CrsGraph::RangeMap ( ) const
inline

Returns the RangeMap associated with this graph.

Precondition
Filled()==true
int Epetra_CrsGraph::ReferenceCount ( ) const
inline

Returns the reference count of CrsGraphData.

(Intended for testing purposes.)

int Epetra_CrsGraph::RemoveEmptyProcessesInPlace ( const Epetra_BlockMap NewMap)

Remove processes owning zero rows from the Maps and their communicator.

Remove processes owning zero rows from the Maps and their communicator.

Warning
This method is ONLY for use by experts.
We make NO promises of backwards compatibility. This method may change or disappear at any time.
Parameters
newMap[in] This must be the result of calling the removeEmptyProcesses() method on the row BlockMap. If it is not, this method's behavior is undefined. This pointer will be null on excluded processes.
int Epetra_CrsGraph::RemoveGlobalIndices ( int  GlobalRow,
int  NumIndices,
int *  Indices
)

Remove a list of elements from a specified global row of the graph.

Parameters
Row- (In) Global row number of indices.
NumIndices- (In) Number of Indices.
Indices- (In) Global column indices to remove.
Returns
Integer error code, set to 0 if successful. Returns 1 if data is shared.
Precondition
IndicesAreGlobal()==true, StorageOptimized()==false
int Epetra_CrsGraph::RemoveGlobalIndices ( long long  Row)

Remove all indices from a specified global row of the graph.

Parameters
Row- (In) Global row number of indices.
Returns
Integer error code, set to 0 if successful. Returns 1 if data is shared.
Precondition
IndicesAreGlobal()==true, StorageOptimized()==false
int Epetra_CrsGraph::RemoveMyIndices ( int  LocalRow,
int  NumIndices,
int *  Indices
)

Remove a list of elements from a specified local row of the graph.

Parameters
Row- (In) Local row number of indices.
NumIndices- (In) Number of Indices.
Indices- (In) Local column indices to remove.
Returns
Integer error code, set to 0 if successful. Returns 1 if data is shared.
Precondition
IndicesAreLocal()==true, StorageOptimized()==false
int Epetra_CrsGraph::RemoveMyIndices ( int  Row)

Remove all indices from a specified local row of the graph.

Parameters
Row- (In) Local row number of indices.
Returns
Integer error code, set to 0 if successful. Returns 1 if data is shared.
Precondition
IndicesAreLocal()==true, StorageOptimized()==false
int Epetra_CrsGraph::RemoveRedundantIndices ( )
protected

Removes any redundant column indices in the rows of the graph.

Returns
Integer error code, set to 0 if successful. Returns 1 if data is shared.
int Epetra_CrsGraph::ReplaceColMap ( const Epetra_BlockMap newmap)

Replaces the current ColMap with the user-specified map object, but only if no entries have been inserted into the graph yet (both IndicesAreLocal() and IndicesAreGlobal() are false) or currentmap->PointSameAs(newmap) is true. This is a collective function. Returns 0 if map is replaced, -1 if not.

Precondition
(IndicesAreLocal()==false && IndicesAreGlobal()==false) || ColMap().PointSameAs(newmap)==true
int Epetra_CrsGraph::ReplaceDomainMapAndImporter ( const Epetra_BlockMap NewDomainMap,
const Epetra_Import NewImporter
)

Replaces the current DomainMap & Importer with the user-specified map object.

Replaces the current DomainMap and Importer with the user-specified map object, but only if the matrix has been FillCompleted, Importer's TargetMap matches the ColMap and Importer's SourceMap matches the DomainMap (assuming the importer isn't null). If an Importer is passed in, Epetra_CrsMatrix will copy it. Returns 0 if map/importer is replaced, -1 if not.

Precondition
(!NewImporter && ColMap().PointSameAs(NewDomainMap)) || (NewImporter && ColMap().PointSameAs(NewImporter->TargetMap()) && NewDomainMap.PointSameAs(NewImporter->SourceMap()))
int Epetra_CrsGraph::ReplaceRowMap ( const Epetra_BlockMap newmap)

Replaces the current RowMap with the user-specified map object, but only if currentmap->PointSameAs(newmap) is true. This is a collective function. Returns 0 if map is replaced, -1 if not.

Precondition
RowMap().PointSameAs(newmap)==true
void Epetra_CrsGraph::SortGhostsAssociatedWithEachProcessor ( bool  Flag)
inline

Forces FillComplete() to locally order ghostnodes associated with each remote processor in ascending order.

To be compliant with AztecOO, FillComplete() already locally orders ghostnodes such that information received from processor k has a lower local numbering than information received from processor j if k is less than j. SortGhostsAssociatedWithEachProcessor(True) further forces FillComplete() to locally number all ghostnodes received from processor k in ascending order. That is, the local numbering of b is less than c if the global numbering of b is less than c and if both b and c are owned by the same processor. This is done to be compliant with some limited block features within ML. In particular, some ML features require that a block structure of the matrix be maintained even within the ghost variables.

int Epetra_CrsGraph::SortIndices ( )
protected

Sort column indices, row-by-row, in ascending order.

Returns
Integer error code, set to 0 if successful. Returns 1 if data is shared.
bool Epetra_CrsGraph::UpperTriangular ( ) const
inline

If graph is upper triangular in local index space, this query returns true, otherwise it returns false.

Precondition
Filled()==true

The documentation for this class was generated from the following file:
