example_Poisson_stk.cpp File Reference

Example solution of a Poisson equation on a hexahedral or tetrahedral mesh using nodal (Hgrad) elements. More...

#include <unistd.h>
#include <Teuchos_CommandLineProcessor.hpp>
#include "Intrepid_FunctionSpaceTools.hpp"
#include "Intrepid_CellTools.hpp"
#include "Intrepid_ArrayTools.hpp"
#include "Intrepid_Basis.hpp"
#include "Intrepid_HGRAD_HEX_C1_FEM.hpp"
#include "Intrepid_HGRAD_TET_C1_FEM.hpp"
#include "Intrepid_RealSpaceTools.hpp"
#include "Intrepid_DefaultCubatureFactory.hpp"
#include "Intrepid_Utils.hpp"
#include "Epetra_Time.h"
#include "Epetra_Map.h"
#include "Epetra_MpiComm.h"
#include "Epetra_FECrsMatrix.h"
#include "Epetra_FEVector.h"
#include "Epetra_Import.h"
#include "Teuchos_oblackholestream.hpp"
#include "Teuchos_RCP.hpp"
#include "Teuchos_BLAS.hpp"
#include "Teuchos_GlobalMPISession.hpp"
#include "Teuchos_XMLParameterListHelpers.hpp"
#include "Shards_CellTopology.hpp"
#include "EpetraExt_RowMatrixOut.h"
#include "EpetraExt_MultiVectorOut.h"
#include "AztecOO.h"
#include "ml_MultiLevelPreconditioner.h"
#include "ml_epetra_utils.h"
#include "Sacado_No_Kokkos.hpp"
#include "Ionit_Initializer.h"
#include "Ioss_SubSystem.h"
#include "stk_io/IossBridge.hpp"
#include "stk_io/StkMeshIoBroker.hpp"
#include "stk_util/parallel/Parallel.hpp"
#include "stk_mesh/base/MetaData.hpp"
#include "stk_mesh/base/CoordinateSystems.hpp"
#include "stk_mesh/base/BulkData.hpp"
#include "stk_mesh/base/Comm.hpp"
#include "stk_mesh/base/Selector.hpp"
#include "stk_mesh/base/GetEntities.hpp"
#include "stk_mesh/base/GetBuckets.hpp"
#include "stk_mesh/base/CreateAdjacentEntities.hpp"
#include <stk_mesh/base/FEMHelpers.hpp>
#include <stk_mesh/base/Field.hpp>
#include "stk_mesh/base/Bucket.hpp"
#include "stk_mesh/base/Entity.hpp"
#include "stk_mesh/base/FieldBase.hpp"
#include "stk_mesh/base/Types.hpp"
Include dependency graph for example_Poisson_stk.cpp:

Typedefs

typedef Sacado::Fad::SFad
< double, 3 >
Fad3

typedef shards::CellTopology ShardsCellTopology

typedef
Intrepid::FunctionSpaceTools
IntrepidFSTools

typedef
Intrepid::RealSpaceTools
< double >
IntrepidRSTools

typedef Intrepid::CellTools
< double >
IntrepidCTools

typedef
Intrepid::FieldContainer
< double >
IntrepidFieldContainer


Functions

template<typename Scalar >
const Scalar exactSolution (const Scalar &x, const Scalar &y, const Scalar &z)
 User-defined exact solution. More...

template<typename Scalar >
void materialTensor (Scalar material[][3], const Scalar &x, const Scalar &y, const Scalar &z)
 User-defined material tensor. More...

template<typename Scalar >
void exactSolutionGrad (Scalar gradExact[3], const Scalar &x, const Scalar &y, const Scalar &z)
 Computes gradient of the exact solution. Requires user-defined exact solution. More...

template<typename Scalar >
const Scalar sourceTerm (Scalar &x, Scalar &y, Scalar &z)
 Computes source term: f = -div(A.grad u). Requires user-defined exact solution and material tensor. More...

template<class ArrayOut , class ArrayIn >
void evaluateMaterialTensor (ArrayOut &worksetMaterialValues, const ArrayIn &evaluationPoints)
 Computation of the material tensor at array of points in physical space. More...

template<class ArrayOut , class ArrayIn >
void evaluateSourceTerm (ArrayOut &sourceTermValues, const ArrayIn &evaluationPoints)
 Computation of the source term at array of points in physical space. More...

template<class ArrayOut , class ArrayIn >
void evaluateExactSolution (ArrayOut &exactSolutionValues, const ArrayIn &evaluationPoints)
 Computation of the exact solution at array of points in physical space. More...

template<class ArrayOut , class ArrayIn >
void evaluateExactSolutionGrad (ArrayOut &exactSolutionGradValues, const ArrayIn &evaluationPoints)
 Computation of the gradient of the exact solution at array of points in physical space. More...

int TestMultiLevelPreconditioner (char ProblemType[], Teuchos::ParameterList &MLList, Epetra_CrsMatrix &A, const Epetra_MultiVector &xexact, Epetra_MultiVector &b, Epetra_MultiVector &uh, double &TotalErrorResidual, double &TotalErrorExactSol)

void getBasis (Teuchos::RCP< Intrepid::Basis< double, IntrepidFieldContainer > > &basis, const ShardsCellTopology &cellTopology, int order)
 Simple factory that chooses basis function based on cell topology. More...

void mesh_read_write (const std::string &type, const std::string &working_directory, const std::string &filename, stk::io::StkMeshIoBroker &broker, int db_integer_size, stk::io::HeartbeatType hb_type)

int main (int argc, char *argv[])


Detailed Description

Example solution of a Poisson equation on a hexahedral or tetrahedral mesh using nodal (Hgrad) elements.

    This example requires a hexahedral or tetrahedral mesh in Exodus
    format with a nodeset containing boundary nodes. STK is used to
    read the mesh and populate a mesh database, Intrepid is used to
    build the stiffness matrix and right-hand side, and ML is used
    to solve the resulting linear system.
 Poisson system:

        div A grad u = f in Omega
                   u = g on Gamma

   where
         A is a symmetric, positive definite material tensor
         f is a given source term


 Corresponding discrete linear system for nodal coefficients(x):

             Kx = b

        K - HGrad stiffness matrix
        b - right hand side vector
Author
Created by P. Bochev, D. Ridzal, K. Peterson C. Siefert.
Remarks
Usage:
./example_Poisson_stk --help
Example requires a hexahedral or tetrahedral mesh in Exodus format

Function Documentation

template<class ArrayOut , class ArrayIn >
void evaluateExactSolution ( ArrayOut &  exactSolutionValues,
const ArrayIn &  evaluationPoints
)

Computation of the exact solution at array of points in physical space.

Parameters
exactSolutionValues[out] Rank-2 (C,P) array with the values of the exact solution
evaluationPoints[in] Rank-3 (C,P,D) array with the evaluation points in physical frame
template<class ArrayOut , class ArrayIn >
void evaluateExactSolutionGrad ( ArrayOut &  exactSolutionGradValues,
const ArrayIn &  evaluationPoints
)

Computation of the gradient of the exact solution at array of points in physical space.

Parameters
exactSolutionGradValues[out] Rank-3 (C,P,D) array with the values of the gradient of the exact solution
evaluationPoints[in] Rank-3 (C,P,D) array with the evaluation points in physical frame
template<class ArrayOut , class ArrayIn >
void evaluateMaterialTensor ( ArrayOut &  worksetMaterialValues,
const ArrayIn &  evaluationPoints
)

Computation of the material tensor at array of points in physical space.

Parameters
worksetMaterialValues[out] Rank-2, 3 or 4 array with dimensions (C,P), (C,P,D) or (C,P,D,D) with the values of the material tensor
evaluationPoints[in] Rank-3 (C,P,D) array with the evaluation points in physical frame
template<class ArrayOut , class ArrayIn >
void evaluateSourceTerm ( ArrayOut &  sourceTermValues,
const ArrayIn &  evaluationPoints
)

Computation of the source term at array of points in physical space.

Parameters
sourceTermValues[out] Rank-2 (C,P) array with the values of the source term
evaluationPoints[in] Rank-3 (C,P,D) array with the evaluation points in physical frame
template<typename Scalar >
const Scalar exactSolution ( const Scalar &  x,
const Scalar &  y,
const Scalar &  z
)

User-defined exact solution.

Parameters
x[in] x-coordinate of the evaluation point
y[in] y-coordinate of the evaluation point
z[in] z-coordinate of the evaluation point
Returns
Value of the exact solution at (x,y,z)
template<typename Scalar >
void exactSolutionGrad ( Scalar  gradExact[3],
const Scalar &  x,
const Scalar &  y,
const Scalar &  z
)

Computes gradient of the exact solution. Requires user-defined exact solution.

Parameters
gradExact[out] gradient of the exact solution evaluated at (x,y,z)
x[in] x-coordinate of the evaluation point
y[in] y-coordinate of the evaluation point
z[in] z-coordinate of the evaluation point
void getBasis ( Teuchos::RCP< Intrepid::Basis< double, IntrepidFieldContainer > > &  basis,
const ShardsCellTopology &  cellTopology,
int  order
)

Simple factory that chooses basis function based on cell topology.

Parameters
cellTopology[in] Shards cell topology
order[in] basis function order, currently unused
basis[out] pointer to Intrepid basis
Returns
Intrepid basis
template<typename Scalar >
void materialTensor ( Scalar  material[][3],
const Scalar &  x,
const Scalar &  y,
const Scalar &  z
)

User-defined material tensor.

Parameters
material[out] 3 x 3 material tensor evaluated at (x,y,z)
x[in] x-coordinate of the evaluation point
y[in] y-coordinate of the evaluation point
z[in] z-coordinate of the evaluation point
Warning
Symmetric and positive definite tensor is required for every (x,y,z).
template<typename Scalar >
const Scalar sourceTerm ( Scalar &  x,
Scalar &  y,
Scalar &  z
)

Computes source term: f = -div(A.grad u). Requires user-defined exact solution and material tensor.

Parameters
x[in] x-coordinate of the evaluation point
y[in] y-coordinate of the evaluation point
z[in] z-coordinate of the evaluation point
Returns
Source term corresponding to the user-defined exact solution evaluated at (x,y,z)
