Abstract interface for objects that represent a space for vectors. More...
#include <Thyra_VectorSpaceBase_decl.hpp>
Related Functions | |
(Note that these are not member functions.) | |
template<class Scalar > | |
RCP< const VectorSpaceBase < Scalar > > | makeHaveOwnership (const RCP< const VectorSpaceBase< Scalar > > &vs) |
Helper function that clones a VectorSpaceBase object if the RCP does not have ownership. More... | |
template<class Scalar > | |
RCP< VectorBase< Scalar > > | createMember (const RCP< const VectorSpaceBase< Scalar > > &vs, const std::string &label="") |
Create a vector member from the vector space. More... | |
template<class Scalar > | |
RCP< VectorBase< Scalar > > | createMember (const VectorSpaceBase< Scalar > &vs, const std::string &label="") |
Calls createMember(Teuchos::rcp(&vs,false)) . More... | |
template<class Scalar > | |
RCP< MultiVectorBase< Scalar > > | createMembers (const RCP< const VectorSpaceBase< Scalar > > &vs, int numMembers, const std::string &label="") |
Create a set of vector members (a MultiVectorBase ) from the vector space. More... | |
template<class Scalar > | |
RCP< MultiVectorBase< Scalar > > | createMembers (const RCP< const VectorSpaceBase< Scalar > > &vs, const RCP< const VectorSpaceBase< Scalar > > &domain, const std::string &label="") |
Create a set of vector members (a MultiVectorBase ) from the vector space. More... | |
template<class Scalar > | |
RCP< MultiVectorBase< Scalar > > | createMembers (const VectorSpaceBase< Scalar > &vs, int numMembers, const std::string &label="") |
Calls createMembers(Teuchos::rcp(&vs,false),numMembers) . More... | |
template<class Scalar > | |
RCP< VectorBase< Scalar > > | createMemberView (const RCP< const VectorSpaceBase< Scalar > > &vs, const RTOpPack::SubVectorView< Scalar > &raw_v, const std::string &label="") |
Create a vector member that is a non-const view of raw data. More... | |
template<class Scalar > | |
RCP< VectorBase< Scalar > > | createMemberView (const VectorSpaceBase< Scalar > &vs, const RTOpPack::SubVectorView< Scalar > &raw_v, const std::string &label="") |
Calls createMemberView(Teuchos::rcp(&vs,false),raw_v) . More... | |
template<class Scalar > | |
RCP< const VectorBase< Scalar > > | createMemberView (const RCP< const VectorSpaceBase< Scalar > > &vs, const RTOpPack::ConstSubVectorView< Scalar > &raw_v, const std::string &label="") |
Create a vector member that is a const view of raw data. More... | |
template<class Scalar > | |
RCP< const VectorBase< Scalar > > | createMemberView (const VectorSpaceBase< Scalar > &vs, const RTOpPack::ConstSubVectorView< Scalar > &raw_v, const std::string &label="") |
Calls createMemberView(Teuchos::rcp(&vs,false),raw_v) . More... | |
template<class Scalar > | |
RCP< MultiVectorBase< Scalar > > | createMembersView (const RCP< const VectorSpaceBase< Scalar > > &vs, const RTOpPack::SubMultiVectorView< Scalar > &raw_mv, const std::string &label="") |
Create a multi-vector member that is a non-const view of raw data. More... | |
template<class Scalar > | |
RCP< MultiVectorBase< Scalar > > | createMembersView (const VectorSpaceBase< Scalar > &vs, const RTOpPack::SubMultiVectorView< Scalar > &raw_mv, const std::string &label="") |
Calls createMembersView(Teuchos::rcp(&vs,false),raw_mv) . More... | |
template<class Scalar > | |
RCP< const MultiVectorBase < Scalar > > | createMembersView (const RCP< const VectorSpaceBase< Scalar > > &vs, const RTOpPack::ConstSubMultiVectorView< Scalar > &raw_mv, const std::string &label="") |
Create a multi-vector member that is a const view of raw data. More... | |
template<class Scalar > | |
RCP< const MultiVectorBase < Scalar > > | createMembersView (const VectorSpaceBase< Scalar > &vs, const RTOpPack::ConstSubMultiVectorView< Scalar > &raw_mv, const std::string &label="") |
Calls createMembersView(Teuchos::rcp(&vs,false),raw_mv) . More... | |
Public pure virtual functions that must be overridden | |
virtual Ordinal | dim () const =0 |
Return the dimension of the vector space. More... | |
virtual bool | isCompatible (const VectorSpaceBase< Scalar > &vecSpc) const =0 |
Compare the compatibility of two vector spaces. More... | |
virtual RCP< const VectorSpaceFactoryBase< Scalar > > | smallVecSpcFcty () const =0 |
Return a VectorSpaceFactoryBase object for the creation of (usually serial) vector spaces with a small dimension. More... | |
virtual Scalar | scalarProd (const VectorBase< Scalar > &x, const VectorBase< Scalar > &y) const =0 |
Return the scalar product of two vectors in the vector space. More... | |
void | scalarProds (const MultiVectorBase< Scalar > &X, const MultiVectorBase< Scalar > &Y, const ArrayView< Scalar > &scalarProds_out) const |
Return the scalar product of each column in two multi-vectors in the vector space. More... | |
Public virtual functions with default implementations | |
virtual bool | isEuclidean () const |
Return if this vector space has a Euclidean (identity) basis in which case the scalar product is the same as the dot product. More... | |
virtual bool | hasInCoreView (const Range1D &rng=Range1D(), const EViewType viewType=VIEW_TYPE_DETACHED, const EStrideType strideType=STRIDE_TYPE_NONUNIT) const |
Returns true if this->acquireDetachedView(rng,...) returns a direct view of the range of data requested. More... | |
virtual RCP< const VectorSpaceBase< Scalar > > | clone () const |
Clone this object (if supported). More... | |
Protected pure virtual functions that must be overridden | |
virtual RCP< VectorBase< Scalar > > | createMember () const =0 |
Create a vector member from the vector space. More... | |
virtual RCP< MultiVectorBase < Scalar > > | createMembers (int numMembers) const =0 |
Create a set of vector members (a MultiVectorBase ) from the vector space. More... | |
virtual RCP< VectorBase< Scalar > > | createMemberView (const RTOpPack::SubVectorView< Scalar > &raw_v) const =0 |
Create a vector member that is a non-const view of raw vector data. More... | |
virtual RCP< const VectorBase < Scalar > > | createMemberView (const RTOpPack::ConstSubVectorView< Scalar > &raw_v) const =0 |
Create a vector member that is a const view of raw vector data. More... | |
virtual RCP< MultiVectorBase < Scalar > > | createMembersView (const RTOpPack::SubMultiVectorView< Scalar > &raw_mv) const =0 |
Create a multi-vector member that is a non-const view of raw multi-vector data. More... | |
virtual RCP< const MultiVectorBase< Scalar > > | createMembersView (const RTOpPack::ConstSubMultiVectorView< Scalar > &raw_mv) const =0 |
Create a multi-vector member that is a const view of raw multi-vector data. More... | |
Protected virtual funtions. | |
virtual void | scalarProdsImpl (const MultiVectorBase< Scalar > &X, const MultiVectorBase< Scalar > &Y, const ArrayView< Scalar > &scalarProds) const =0 |
Abstract interface for objects that represent a space for vectors.
This interface acts primarily as an "Abstract Factory" interface for creating VectorBase
objects using the non-member function Thyra::createMember()
. A VectorSpaceBase
can also create MultiVectorBase
objects which represent a compact collection of vectors using the non-member function Thyra::createMembers()
. A secondary role for VectorSpaceBase
objects is to test for compatibility of vector space objects using the isCompatible()
method and to apply the space's scalar (inner) product.
Clients can not directly create VectorBase
and MultiVectorBase
objects using the member functions createMember()
, createMembers()
, createMemberView()
, and createMembersView()
but instead must use the non-member Thyra_Op_Vec_createMember_grp.
Note that a VectorSpaceBase
object must also be able to create MultiVectorBase
objects with any number of column vectors using the Thyra::createMembers()
function. Once created, the LinearOpBase::domain()
function supported by a created MultiVectorBase
object returns a vector space of dimension equal to the number of columns in the multi-vector. An interesting implication of this design is that the creation of a multi-vector provides a way for clients to create vector spaces of any arbitrary (although small usually) dimension. In order to give the client the same ability to create smaller vector spaces without having to create a dummy multi-vector object first, the method smallVecSpcFcty()
is included. The method smallVecSpcFcty()
returns a VectorSpaceFactoryBase
object that can create (typically serial) vector spaces of any small dimension that are compatible with the domain spaces of MultiVectorBase
objects created by the vector space object.
A vector space is also where the scalar product for the space is defined which is computed by the scalarProd()
method. A scalar product allows the vector space to introduce scaling into many different types of numerical algorithms.
If the underlying object is not initialized, then dim()==0
will be true and none of the other methods should be called or exceptions will be thrown.
Notes for subclass developers
This is a fairly bare-bones interface class without much in the way of default function implementations. The subclass VectorSpaceDefaultBase
provides a default multi-vector implementation and should the the first choice for subclass implementations.
Definition at line 367 of file Thyra_OperatorVectorTypes.hpp.
|
pure virtual |
Return the dimension of the vector space.
If the underlying object is not initialized, then dim()==0
will be true and none of the other methods should be called.
Implemented in Thyra::DefaultProductVectorSpace< Scalar >, Thyra::DefaultClusteredSpmdProductVectorSpace< Scalar >, Thyra::SpmdVectorSpaceDefaultBase< Scalar >, and Thyra::DefaultMultiVectorProductVectorSpace< Scalar >.
|
pure virtual |
Compare the compatibility of two vector spaces.
If this function returns true
, then vectors created from either of the vector spaces will be compatible and can be combined in vector operations.
Preconditions:
this->dim() > 0
Postconditions:
[this->dim() != vecSpc.dim()
] returnVal == false
Invariants:
[this->isCompatible(vecSpc) == true
] vecSpc.isCompatible(*this) == true
Implemented in Thyra::DefaultProductVectorSpace< Scalar >, Thyra::SpmdVectorSpaceDefaultBase< Scalar >, Thyra::DefaultClusteredSpmdProductVectorSpace< Scalar >, and Thyra::DefaultMultiVectorProductVectorSpace< Scalar >.
|
pure virtual |
Return a VectorSpaceFactoryBase
object for the creation of (usually serial) vector spaces with a small dimension.
Preconditions:
this->dim() > 0
Implemented in Thyra::DefaultProductVectorSpace< Scalar >, Thyra::DefaultClusteredSpmdProductVectorSpace< Scalar >, Thyra::DefaultMultiVectorProductVectorSpace< Scalar >, and Thyra::SpmdVectorSpaceDefaultBase< Scalar >.
|
pure virtual |
Return the scalar product of two vectors in the vector space.
Preconditions:
x.space()->isCompatible(*this)
(throw Exceptions::IncompatibleVectorSpaces
)
y.space()->isCompatible(*this)
(throw Exceptions::IncompatibleVectorSpaces
)
Implemented in Thyra::DefaultProductVectorSpace< Scalar >, Thyra::DefaultClusteredSpmdProductVectorSpace< Scalar >, Thyra::ScalarProdVectorSpaceBase< Scalar >, and Thyra::DefaultMultiVectorProductVectorSpace< Scalar >.
|
inline |
Return the scalar product of each column in two multi-vectors in the vector space.
X | [in] Multi-vector. |
Y | [in] Multi-vector. |
scalarProds_out | [out] Array (length X.domain()->dim() ) containing the scalar products scalarProds_out[j] = this->scalarProds_out(*X.col(j),*Y.col(j)) , for j = 0 ... X.domain()->dim()-1 . |
Preconditions:
X.range()->isCompatible(*this)
(throw Exceptions::IncompatibleVectorSpaces
)
Y.range()->isCompatible(*this)
(throw Exceptions::IncompatibleVectorSpaces
)
X.domain()->isCompatible(*Y.domain())
(throw Exceptions::IncompatibleVectorSpaces
)
Definition at line 387 of file Thyra_VectorSpaceBase_decl.hpp.
|
virtual |
Return if this vector space has a Euclidean (identity) basis in which case the scalar product is the same as the dot product.
The default implementation returns false
(even though on average the Euclidean scalar product is used).
Reimplemented in Thyra::DefaultClusteredSpmdProductVectorSpace< Scalar >, and Thyra::ScalarProdVectorSpaceBase< Scalar >.
Definition at line 69 of file Thyra_VectorSpaceBase_def.hpp.
|
virtual |
Returns true
if this->acquireDetachedView(rng,...)
returns a direct view of the range of data requested.
rng | [in] The range of elements for the view (see acquireDetachedView() ). The default value is Range1D() (i.e. All of the elements in the vector). |
viewType | [in] The type of view allowed. |
strideType | [in] The type of stride the view is allowed to be. |
Preconditions:
There are three different questions about the behavior of the acquireDetachedView()
that this query function can answer:
The elements in rng
are fairly cheaply accessble in local (i.e. in-core) memory if this->hasInCoreView(rng)==true
. Note that this also allows for detached temporary copies of data.
A direct view of the elements in rng
is available in local (i.e. in-core) memory if this->hasInCoreView(rng,VIEW_TYPE_DIRECT)==true
. No copy of data is allowed here.
A direct view of the elements in rng
with unit stride is available in local (i.e. in-core) memory if this->hasInCoreView(rng,VIEW_TYPE_DIRECT,STRIDE_TYPE_UNIT)==true
No copy of data is allowed here.
The default implementation returns false
(i.e. by default we do not assume that any direct and/or contiguous views of any range of data are provided).
Reimplemented in Thyra::DefaultProductVectorSpace< Scalar >, Thyra::DefaultClusteredSpmdProductVectorSpace< Scalar >, Thyra::DefaultSpmdVectorSpace< Scalar >, Thyra::DefaultMultiVectorProductVectorSpace< Scalar >, and Thyra::TpetraVectorSpace< Scalar, LocalOrdinal, GlobalOrdinal, Node >.
Definition at line 76 of file Thyra_VectorSpaceBase_def.hpp.
|
virtual |
Clone this object (if supported).
It is allowed for returnVal.get()==NULL
which means that this capability is optional.
Preconditions:
this->dim() > 0
The default implementation returns returnVal.get()==NULL
.
Reimplemented in Thyra::DefaultProductVectorSpace< Scalar >, Thyra::DefaultClusteredSpmdProductVectorSpace< Scalar >, Thyra::DefaultMultiVectorProductVectorSpace< Scalar >, Thyra::DefaultSpmdVectorSpace< Scalar >, and Thyra::TpetraVectorSpace< Scalar, LocalOrdinal, GlobalOrdinal, Node >.
Definition at line 85 of file Thyra_VectorSpaceBase_def.hpp.
|
protectedpure virtual |
Create a vector member from the vector space.
Preconditions:
this->dim() > 0
Postconditions:
returnVal.get() != NULL
returnVal->space()->isCompatible(*this) == true
Note: This function is not to be called directly since it is protected! See the Thyra_Op_Vec_createMember_grp.
*returnVal
are unspecified (uninitialized). This allows for faster execution times. Note that returnVal->space().get() == this
need not be true. Implemented in Thyra::DefaultProductVectorSpace< Scalar >, Thyra::DefaultClusteredSpmdProductVectorSpace< Scalar >, Thyra::DefaultSpmdVectorSpace< Scalar >, Thyra::DefaultMultiVectorProductVectorSpace< Scalar >, and Thyra::TpetraVectorSpace< Scalar, LocalOrdinal, GlobalOrdinal, Node >.
|
protectedpure virtual |
Create a set of vector members (a MultiVectorBase
) from the vector space.
Preconditions:
this->dim() > 0
num_vecs >= 1
Postconditions:
returnVal->range()->isCompatible(*this) == true
returnVal->domain()->dim() == numMembers
*returnVal
are unspecified (uninitialized). This allows for faster execution times. Note that returnVal->range().get()==this
does not have to be true but will be in may cases. Implemented in Thyra::DefaultProductVectorSpace< Scalar >, Thyra::DefaultClusteredSpmdProductVectorSpace< Scalar >, Thyra::DefaultSpmdVectorSpace< Scalar >, Thyra::DefaultMultiVectorProductVectorSpace< Scalar >, Thyra::TpetraVectorSpace< Scalar, LocalOrdinal, GlobalOrdinal, Node >, and Thyra::VectorSpaceDefaultBase< Scalar >.
|
protectedpure virtual |
Create a vector member that is a non-const
view of raw vector data.
raw_v | [in] On input contains pointer (i.e. raw_v.values() ) to array that the returned VectorBase will be a view of. The data pointed to by raw_v.values() must remain valid until the returned VectorBase object is destroyed. |
Preconditions:
raw_v
has been initialized to memory (i.e. raw_v.subDim()!=0 && raw_v.values()!=NULL
).
raw_v
is consistent with the local storage of this vector spaces vector data. This precondition is purposefully vague since this function can be used an variety of specialized use-cases.
Postconditions:
See this->createMember()
It is stated here that the client can not expect that the values pointed to by raw_v.values()
to be changed until the smart pointer returnVal
goes out of scope. This is to allow an implementation that temporarily copies data into and out of a VectorBase
object using explicit vector access.
Implemented in Thyra::DefaultSpmdVectorSpace< Scalar >, and Thyra::VectorSpaceDefaultBase< Scalar >.
|
protectedpure virtual |
Create a vector member that is a const
view of raw vector data.
raw_v | [in] On input contains pointer (i.e. raw_v.values() ) to array that the returned VectorBase will be a view of. The data pointed to by raw_v.values() must remain valid until the returned VectorBase object is destroyed. |
This function works exactly the same as the previous version that takes a RTOpPack::SubVectorView
object except that this version takes a RTOpPack::ConstSubVectorView
and returns a smart pointer to a const
VectorBase
object.
Preconditions:
RTOpPack::SubVectorView
version of this function. Postconditions:
this->createMember()
Implemented in Thyra::DefaultSpmdVectorSpace< Scalar >, and Thyra::VectorSpaceDefaultBase< Scalar >.
|
protectedpure virtual |
Create a multi-vector member that is a non-const
view of raw multi-vector data.
raw_mv | [in] On input contains pointer (i.e. raw_mv.values() ) to array that the returned MultiVectorBase will be a view of. |
Preconditions:
raw_mv
has been initialized to memory (i.e. raw_mv.subDim()!=0 && raw_mv.values()!=NULL
).
raw_mv
is consistent with the local storage of this spaces vector data. This precondition is purposefully vague since this function can be used an variety of specialized use-cases.
Postconditions:
See this->createMembers()
where numMembers==raw_mv.numSubCols()
It is stated here that the client can not expect that the values pointed to by raw_mv.values()
to be changed until the smart pointer returnVal
goes out of scope. This is to allow for an implementation that temporarily copies data into and out of a MultiVectorBase
object using explicit vector access.
Implemented in Thyra::DefaultSpmdVectorSpace< Scalar >, and Thyra::VectorSpaceDefaultBase< Scalar >.
|
protectedpure virtual |
Create a multi-vector member that is a const
view of raw multi-vector data.
raw_mv | [in] On input contains pointer (i.e. raw_mv.values() ) to array that the returned MultiVectorBase will be a view of. The data pointed to by raw_mv.values() must remain valid until the returned MultiVectorBase object is destroyed. |
This function works exactly the same as the previous version that takes a RTOpPack::SubMultiVectorView
object except that this version takes a RTOpPack::ConstSubMultiVectorView
object and returns a smart pointer to a const
MultiVectorBase
object.
Preconditions:
See the previous RTOpPack::SubMultiVectorView
version of this function.
Postconditions:
See this->createMember()
Implemented in Thyra::DefaultSpmdVectorSpace< Scalar >, and Thyra::VectorSpaceDefaultBase< Scalar >.
|
protectedpure virtual |
|
related |
Helper function that clones a VectorSpaceBase
object if the RCP
does not have ownership.
|
related |
Create a vector member from the vector space.
Calls VectorSpaceBase::createMember()
on vs
but the returned VectorBase
object can live past vs
.
|
related |
Calls createMember(Teuchos::rcp(&vs,false))
.
|
related |
Create a set of vector members (a MultiVectorBase
) from the vector space.
Calls VectorSpaceBase::createMembers()
on vs
but the returned MultiVectorBase
object can live past vs
.
|
related |
Create a set of vector members (a MultiVectorBase
) from the vector space.
Calls VectorSpaceBase::createMembers()
on vs
but the returned MultiVectorBase
object can live past vs
.
|
related |
Calls createMembers(Teuchos::rcp(&vs,false),numMembers)
.
|
related |
Create a vector member that is a non-const
view of raw data.
Calls VectorSpaceBase::createMemberView()
on vs
but the returned VectorBase
object can live past vs
.
|
related |
Calls createMemberView(Teuchos::rcp(&vs,false),raw_v)
.
|
related |
Create a vector member that is a const
view of raw data.
Calls VectorSpaceBase::createMemberView()
on vs
but the returned VectorBase
object can live past vs
.
|
related |
Calls createMemberView(Teuchos::rcp(&vs,false),raw_v)
.
|
related |
Create a multi-vector member that is a non-const
view of raw data.
Calls VectorSpaceBase::createMembersView()
on vs
but the returned MultiVectorBase
object can live past vs
.
|
related |
Calls createMembersView(Teuchos::rcp(&vs,false),raw_mv)
.
|
related |
Create a multi-vector member that is a const
view of raw data.
Calls VectorSpaceBase::createMembersView()
on vs
but the returned MultiVectorBase
object can live past vs
.
|
related |
Calls createMembersView(Teuchos::rcp(&vs,false),raw_mv)
.
