Panzer
Version of the Day
|
Computes . More...
#include <Panzer_Integrator_GradBasisDotVector_decl.hpp>
Classes | |
struct | FieldMultTag |
This empty struct allows us to optimize operator()() depending on the number of field multipliers. This is the version that does not use shared memory. More... | |
struct | SharedFieldMultTag |
This empty struct allows us to optimize operator()() depending on the number of field multipliers. This is the shared memory version. More... | |
Public Member Functions | |
Integrator_GradBasisDotVector (const panzer::EvaluatorStyle &evalStyle, const std::string &resName, const std::string &fluxName, const panzer::BasisIRLayout &basis, const panzer::IntegrationRule &ir, const double &multiplier=1, const std::vector< std::string > &fmNames=std::vector< std::string >(), const Teuchos::RCP< PHX::DataLayout > &vecDL=Teuchos::null) | |
Main Constructor. More... | |
Integrator_GradBasisDotVector (const Teuchos::ParameterList &p) | |
ParameterList Constructor. More... | |
void | postRegistrationSetup (typename Traits::SetupData d, PHX::FieldManager< Traits > &fm) |
Post-Registration Setup. More... | |
void | evaluateFields (typename Traits::EvalData d) |
Evaluate Fields. More... | |
template<int NUM_FIELD_MULT> | |
KOKKOS_INLINE_FUNCTION void | operator() (const FieldMultTag< NUM_FIELD_MULT > &tag, const Kokkos::TeamPolicy< PHX::exec_space >::member_type &team) const |
Perform the integration. More... | |
template<int NUM_FIELD_MULT> | |
KOKKOS_INLINE_FUNCTION void | operator() (const SharedFieldMultTag< NUM_FIELD_MULT > &tag, const Kokkos::TeamPolicy< PHX::exec_space >::member_type &team) const |
Perform the integration. More... | |
Public Member Functions inherited from panzer::EvaluatorWithBaseImpl< Traits > | |
void | setDetailsIndex (const int di) |
An evaluator builder sets the details index. More... | |
Public Member Functions inherited from panzer::DomainEvaluator | |
DomainEvaluator (DomainType domain=ALL) | |
Constructor. More... | |
virtual | ~DomainEvaluator ()=default |
Default destructor. More... | |
void | setDomain (const DomainType domain) |
Set the domain for the evaluator. More... | |
DomainType | getDomain () |
Get the domain for the evaluator. More... | |
virtual int | cellStartIndex (const panzer::Workset &workset) const |
Returns the starting cell for the specified domain for a given workset. More... | |
virtual int | cellEndIndex (const panzer::Workset &workset) const |
Returns the non-inclusive end cell for the specified domain for a given workset. More... | |
Private Types | |
using | ScalarT = typename EvalT::ScalarT |
The scalar type. More... | |
using | scratch_view = Kokkos::View< ScalarT *,typename PHX::DevLayout< ScalarT >::type, typename PHX::exec_space::scratch_memory_space, Kokkos::MemoryUnmanaged > |
Type for shared memory. More... | |
Private Member Functions | |
Teuchos::RCP < Teuchos::ParameterList > | getValidParameters () const |
Get Valid Parameters. More... | |
Private Attributes | |
const panzer::EvaluatorStyle | evalStyle_ |
An enum determining the behavior of this Evaluator . More... | |
PHX::MDField< ScalarT, panzer::Cell, panzer::BASIS > | field_ |
A field to which we'll contribute, or in which we'll store, the result of computing this integral. More... | |
PHX::MDField< const ScalarT, panzer::Cell, panzer::IP, panzer::Dim > | vector_ |
A field representing the vector-valued function we're integrating ( ). More... | |
double | multiplier_ |
The scalar multiplier out in front of the integral ( ). More... | |
std::vector< PHX::MDField < const ScalarT, panzer::Cell, panzer::IP > > | fieldMults_ |
The (possibly empty) list of fields that are multipliers out in front of the integral ( , , etc.). More... | |
Kokkos::View< Kokkos::View < const ScalarT **, typename PHX::DevLayout< ScalarT > ::type, PHX::Device > * > | kokkosFieldMults_ |
The Kokkos::View representation of the (possibly empty) list of fields that are multipliers out in front of the integral ( , , etc.). More... | |
std::string | basisName_ |
The name of the basis we're using. More... | |
std::size_t | basisIndex_ |
The index in the Workset bases for our particular BasisIRLayout name. More... | |
PHX::MDField< double, panzer::Cell, panzer::BASIS, panzer::IP, panzer::Dim > | basis_ |
The gradient vector basis information necessary for integration. More... | |
Additional Inherited Members | |
Public Types inherited from panzer::DomainEvaluator | |
enum | DomainType : int { OWNED =0, GHOST =1, REAL =2, VIRTUAL =3, ALL =4 } |
Domain types supported by worksets. More... | |
Protected Attributes inherited from panzer::EvaluatorWithBaseImpl< Traits > | |
WorksetDetailsAccessor | wda |
Computes .
Evaluates the integral
where is some constant, , , etc., are some fields that depend on position, is some vector-valued function, and is some basis.
Definition at line 78 of file Panzer_Integrator_GradBasisDotVector_decl.hpp.
|
private |
The scalar type.
Definition at line 294 of file Panzer_Integrator_GradBasisDotVector_decl.hpp.
|
private |
Type for shared memory.
Definition at line 297 of file Panzer_Integrator_GradBasisDotVector_decl.hpp.
panzer::Integrator_GradBasisDotVector< EvalT, Traits >::Integrator_GradBasisDotVector | ( | const panzer::EvaluatorStyle & | evalStyle, |
const std::string & | resName, | ||
const std::string & | fluxName, | ||
const panzer::BasisIRLayout & | basis, | ||
const panzer::IntegrationRule & | ir, | ||
const double & | multiplier = 1 , |
||
const std::vector< std::string > & | fmNames = std::vector<std::string>() , |
||
const Teuchos::RCP< PHX::DataLayout > & | vecDL = Teuchos::null |
||
) |
Main Constructor.
Creates an Evaluator
to evaluate the integral
where is some constant, , , etc., are some fields that depend on position, is some vector-valued function, and is some basis.
[in] | evalStyle | An enum declaring the behavior of this Evaluator , which is to either:
|
[in] | resName | The name of either the contributed or evaluated field, depending on evalStyle . |
[in] | fluxName | The name of the vector-valued function being integrated ( ). |
[in] | basis | The basis that you'd like to use ( ). |
[in] | ir | The integration rule that you'd like to use. |
[in] | multiplier | The scalar multiplier out in front of the integral you're computing ( ). If not specified, this defaults to 1. |
[in] | fmNames | A list of names of fields that are multipliers out in front of the integral you're computing ( , , etc.). If not specified, this defaults to an empty vector . |
[in] | vecDL | The vector data layout that you'd like to use. If not specified, this defaults to Teuchos::null and the vector data layout from the given ir is used. |
std::invalid_argument | If any of the inputs are invalid. |
std::logic_error | If the basis supplied does not support the gradient operator, or if the dimension of the space exceeds the dimension of the vector data layout. |
Definition at line 67 of file Panzer_Integrator_GradBasisDotVector_impl.hpp.
panzer::Integrator_GradBasisDotVector< EvalT, Traits >::Integrator_GradBasisDotVector | ( | const Teuchos::ParameterList & | p | ) |
ParameterList
Constructor.
Creates an Evaluator
to evaluate the integral
where is some constant, , , etc., are some fields that depend on position, is some vector-valued function, and is some basis.
Evaluator
with a ParameterList
; however, it is strongly advised that you not use this ParameterList
Constructor, but rather that you favor the main constructor with its compile-time argument checking instead.[in] | p | A ParameterList of the form <ParameterList>
<Parameter name = "Residual Name" type = "std::string" value = (required) />
<Parameter name = "Flux Name" type = "std::string" value = (required) />
<Parameter name = "Basis" type = "RCP<panzer::BasisIRLayout>" value = (required) />
<Parameter name = "IR" type = "RCP<panzer::IntegrationRule>" value = (required) />
<Parameter name = "Multiplier" type = "double" value = (required) />
<Parameter name = "Field Multipliers" type = "RCP<const std::vector<std::string>>" value = null (default)/>
<Parameter name = "Vector Data Layout" type = "RCP<PHX::DataLayout>" value = null (default)/>
</ParameterList>
|
Definition at line 154 of file Panzer_Integrator_GradBasisDotVector_impl.hpp.
void panzer::Integrator_GradBasisDotVector< EvalT, Traits >::postRegistrationSetup | ( | typename Traits::SetupData | d, |
PHX::FieldManager< Traits > & | fm | ||
) |
Post-Registration Setup.
Sets the basis index, and gets the Kokkos::View versions of the field multiplier, if there are any.
[in] | sd | Essentially a list of Workset s, which are collections of cells (elements) that all live on a single process. |
[in] | fm | This is an unused part of the Evaluator interface. |
Definition at line 188 of file Panzer_Integrator_GradBasisDotVector_impl.hpp.
void panzer::Integrator_GradBasisDotVector< EvalT, Traits >::evaluateFields | ( | typename Traits::EvalData | d | ) |
Evaluate Fields.
This actually performs the integration by calling operator()()
in a Kokkos::parallel_for
over the cells in the Workset
.
[in] | workset | The Workset on which you're going to do the integration. |
Definition at line 410 of file Panzer_Integrator_GradBasisDotVector_impl.hpp.
KOKKOS_INLINE_FUNCTION void panzer::Integrator_GradBasisDotVector< EvalT, Traits >::operator() | ( | const FieldMultTag< NUM_FIELD_MULT > & | tag, |
const Kokkos::TeamPolicy< PHX::exec_space >::member_type & | team | ||
) | const |
Perform the integration.
Generally speaking, for a given cell in the Workset
, this routine loops over quadrature points, vector dimensions, and bases to perform the integration, scaling the vector field to be integrated by the multiplier ( ) and any field multipliers ( , , etc.).
[in] | tag | An indication of the number of field multipliers we have; either 0, 1, or something else. |
[in] | cell | The cell in the Workset over which to integrate. |
Definition at line 215 of file Panzer_Integrator_GradBasisDotVector_impl.hpp.
KOKKOS_INLINE_FUNCTION void panzer::Integrator_GradBasisDotVector< EvalT, Traits >::operator() | ( | const SharedFieldMultTag< NUM_FIELD_MULT > & | tag, |
const Kokkos::TeamPolicy< PHX::exec_space >::member_type & | team | ||
) | const |
Perform the integration.
Generally speaking, for a given cell in the Workset
, this routine loops over quadrature points, vector dimensions, and bases to perform the integration, scaling the vector field to be integrated by the multiplier ( ) and any field multipliers ( , , etc.). Uses Shared memory.
[in] | tag | An indication of the number of field multipliers we have; either 0, 1, or something else. |
[in] | cell | The cell in the Workset over which to integrate. |
Definition at line 300 of file Panzer_Integrator_GradBasisDotVector_impl.hpp.
|
private |
Get Valid Parameters.
Get all the parameters that we support such that the ParameterList
Constructor can do some validation of the input ParameterList
.
ParameterList
with all the valid parameters (keys) in it. The values tied to those keys are meaningless default values. Definition at line 468 of file Panzer_Integrator_GradBasisDotVector_impl.hpp.
|
private |
An enum
determining the behavior of this Evaluator
.
This Evaluator
will compute the result of its integration and then:
Definition at line 308 of file Panzer_Integrator_GradBasisDotVector_decl.hpp.
|
private |
A field to which we'll contribute, or in which we'll store, the result of computing this integral.
Definition at line 314 of file Panzer_Integrator_GradBasisDotVector_decl.hpp.
|
private |
A field representing the vector-valued function we're integrating ( ).
Definition at line 321 of file Panzer_Integrator_GradBasisDotVector_decl.hpp.
|
private |
The scalar multiplier out in front of the integral ( ).
Definition at line 327 of file Panzer_Integrator_GradBasisDotVector_decl.hpp.
|
private |
The (possibly empty) list of fields that are multipliers out in front of the integral ( , , etc.).
Definition at line 334 of file Panzer_Integrator_GradBasisDotVector_decl.hpp.
|
private |
The Kokkos::View
representation of the (possibly empty) list of fields that are multipliers out in front of the integral ( , , etc.).
Definition at line 341 of file Panzer_Integrator_GradBasisDotVector_decl.hpp.
|
private |
The name of the basis we're using.
Definition at line 346 of file Panzer_Integrator_GradBasisDotVector_decl.hpp.
|
private |
The index in the Workset
bases for our particular BasisIRLayout
name.
Definition at line 352 of file Panzer_Integrator_GradBasisDotVector_decl.hpp.
|
private |
The gradient vector basis information necessary for integration.
Definition at line 359 of file Panzer_Integrator_GradBasisDotVector_decl.hpp.
