Tempus_Test::VanDerPolModel< Scalar > Class Template Reference

van der Pol model problem for nonlinear electrical circuit. More...

#include <VanDerPolModel_decl.hpp>

Inheritance diagram for Tempus_Test::VanDerPolModel< Scalar >:
Inheritance graph
[legend]

Public Member Functions

 VanDerPolModel (Teuchos::RCP< Teuchos::ParameterList > pList=Teuchos::null)

Thyra::ModelEvaluatorBase::InArgs
< Scalar >
getExactSolution (double t) const

Thyra::ModelEvaluatorBase::InArgs
< Scalar >
getExactSensSolution (int j, double t) const

- Public Member Functions inherited from Thyra::StateFuncModelEvaluatorBase< Scalar >
RCP< const VectorSpaceBase
< Scalar > >
get_p_space (int l) const

RCP< const Teuchos::Array
< std::string > >
get_p_names (int l) const

RCP< const VectorSpaceBase
< Scalar > >
get_g_space (int j) const

Teuchos::ArrayView< const
std::string >
get_g_names (int j) const

ModelEvaluatorBase::InArgs
< Scalar >
getNominalValues () const

ModelEvaluatorBase::InArgs
< Scalar >
getLowerBounds () const

ModelEvaluatorBase::InArgs
< Scalar >
getUpperBounds () const

RCP< LinearOpBase< Scalar > > create_W_op () const

RCP< PreconditionerBase< Scalar > > create_W_prec () const

RCP< const
LinearOpWithSolveFactoryBase
< Scalar > >
get_W_factory () const

void reportFinalPoint (const ModelEvaluatorBase::InArgs< Scalar > &finalPoint, const bool wasSolved)

- Public Member Functions inherited from Thyra::ModelEvaluator< class >
virtual int Np () const =0

virtual int Ng () const =0

virtual RCP< const
VectorSpaceBase< Scalar > >
get_f_multiplier_space () const =0

virtual RCP< const
VectorSpaceBase< Scalar > >
get_g_multiplier_space (int j) const =0

virtual RCP< LinearOpBase
< Scalar > >
create_DfDp_op (int l) const =0

virtual RCP< LinearOpBase
< Scalar > >
create_DgDx_dot_op (int j) const =0

virtual RCP< LinearOpBase
< Scalar > >
create_DgDx_op (int j) const =0

virtual RCP< LinearOpBase
< Scalar > >
create_DgDp_op (int j, int l) const =0

virtual RCP< LinearOpBase
< Scalar > >
create_hess_f_xx () const =0

virtual RCP< LinearOpBase
< Scalar > >
create_hess_f_xp (int l) const =0

virtual RCP< LinearOpBase
< Scalar > >
create_hess_f_pp (int l1, int l2) const =0

virtual RCP< LinearOpBase
< Scalar > >
create_hess_g_xx (int j) const =0

virtual RCP< LinearOpBase
< Scalar > >
create_hess_g_xp (int j, int l) const =0

virtual RCP< LinearOpBase
< Scalar > >
create_hess_g_pp (int j, int l1, int l2) const =0

virtual
ModelEvaluatorBase::OutArgs
< Scalar >
createOutArgs () const =0

virtual void evalModel (const ModelEvaluatorBase::InArgs< Scalar > &inArgs, const ModelEvaluatorBase::OutArgs< Scalar > &outArgs) const =0

 ModelEvaluatorBase ()

std::string toString (ModelEvaluatorBase::EInArgsMembers)

std::string toString (ModelEvaluatorBase::EOutArgsMembers)

std::string toString (ModelEvaluatorBase::EDerivativeMultiVectorOrientation orientation)

ModelEvaluatorBase::EDerivativeMultiVectorOrientation getOtherDerivativeMultiVectorOrientation (ModelEvaluatorBase::EDerivativeMultiVectorOrientation orientation)

- Public Member Functions inherited from Teuchos::Describable
virtual std::string description () const

virtual void describe (FancyOStream &out, const EVerbosityLevel verbLevel=verbLevel_default) const

void describe (std::ostream &out, const EVerbosityLevel verbLevel=verbLevel_default) const

virtual ~Describable ()

 LabeledObject ()

virtual ~LabeledObject ()

virtual void setObjectLabel (const std::string &objectLabel)

virtual std::string getObjectLabel () const

DescribableStreamManipulatorState describe (const Describable &describable, const EVerbosityLevel verbLevel=Describable::verbLevel_default)

std::ostream & operator<< (std::ostream &os, const DescribableStreamManipulatorState &d)

- Public Member Functions inherited from Teuchos::ParameterListAcceptorDefaultBase
RCP< ParameterListgetNonconstParameterList ()

RCP< ParameterListunsetParameterList ()

RCP< const ParameterListgetParameterList () const


Private Member Functions

void setupInOutArgs_ () const


Private Attributes

int dim_
 Number of state unknowns (2) More...

int Np_
 Number of parameter vectors (1) More...

int np_
 Number of parameters in this vector (1) More...

int Ng_
 Number of observation functions (0) More...

int ng_
 Number of elements in this observation function (0) More...

bool haveIC_
 false => no nominal values are provided (default=true) More...

bool acceptModelParams_
 Changes inArgs to require parameters. More...

bool isInitialized_

Thyra::ModelEvaluatorBase::InArgs
< Scalar >
inArgs_

Thyra::ModelEvaluatorBase::OutArgs
< Scalar >
outArgs_

Thyra::ModelEvaluatorBase::InArgs
< Scalar >
nominalValues_

Teuchos::RCP< const
Thyra::VectorSpaceBase< Scalar > >
x_space_

Teuchos::RCP< const
Thyra::VectorSpaceBase< Scalar > >
f_space_

Teuchos::RCP< const
Thyra::VectorSpaceBase< Scalar > >
p_space_

Teuchos::RCP< const
Thyra::VectorSpaceBase< Scalar > >
g_space_

Scalar epsilon_
 This is a model parameter. More...

Scalar t0_ic_
 initial time More...

Scalar x0_ic_
 initial condition for x0 More...

Scalar x1_ic_
 initial condition for x1 More...


Public functions overridden from ModelEvaluator.

Teuchos::RCP< const
Thyra::VectorSpaceBase< Scalar > >
get_x_space () const

Teuchos::RCP< const
Thyra::VectorSpaceBase< Scalar > >
get_f_space () const

Thyra::ModelEvaluatorBase::InArgs
< Scalar >
getNominalValues () const

Teuchos::RCP
< Thyra::LinearOpWithSolveBase
< Scalar > >
create_W () const

Teuchos::RCP
< Thyra::LinearOpBase< Scalar > >
create_W_op () const

Teuchos::RCP< const
Thyra::LinearOpWithSolveFactoryBase
< Scalar > >
get_W_factory () const

Thyra::ModelEvaluatorBase::InArgs
< Scalar >
createInArgs () const

Teuchos::RCP< const
Thyra::VectorSpaceBase< Scalar > >
get_p_space (int l) const

Teuchos::RCP< const
Teuchos::Array< std::string > >
get_p_names (int l) const

Teuchos::RCP< const
Thyra::VectorSpaceBase< Scalar > >
get_g_space (int j) const


Public functions overridden from ParameterListAcceptor.

void setParameterList (Teuchos::RCP< Teuchos::ParameterList > const &paramList)

Teuchos::RCP< const
Teuchos::ParameterList
getValidParameters () const


Private functions overridden from ModelEvaluatorDefaultBase.

Thyra::ModelEvaluatorBase::OutArgs
< Scalar >
createOutArgsImpl () const

void evalModelImpl (const Thyra::ModelEvaluatorBase::InArgs< Scalar > &inArgs_bar, const Thyra::ModelEvaluatorBase::OutArgs< Scalar > &outArgs_bar) const


Additional Inherited Members

- Public Types inherited from Thyra::ModelEvaluator< class >
enum  EInArgsMembers

enum  EInArgs_p_mp

enum  EEvalType

enum  EDerivativeMultiVectorOrientation

enum  EDerivativeLinearOp

enum  EDerivativeLinearity

enum  ERankStatus

enum  EOutArgsMembers

enum  EOutArgsDfDp

enum  EOutArgsDgDx_dot

enum  EOutArgsDgDx

enum  EOutArgsDgDp

enum  EOutArgs_hess_vec_prod_f_xx

enum  EOutArgs_hess_vec_prod_f_xp

enum  EOutArgs_hess_vec_prod_f_px

enum  EOutArgs_hess_vec_prod_f_pp

enum  EOutArgs_hess_vec_prod_g_xx

enum  EOutArgs_hess_vec_prod_g_xp

enum  EOutArgs_hess_vec_prod_g_px

enum  EOutArgs_hess_vec_prod_g_pp

enum  EOutArgs_hess_f_xx

enum  EOutArgs_hess_f_xp

enum  EOutArgs_hess_f_pp

enum  EOutArgs_hess_g_xx

enum  EOutArgs_hess_g_xp

enum  EOutArgs_hess_g_pp

enum  EOutArgs_H_xx

enum  EOutArgs_H_xp

enum  EOutArgs_H_pp

enum  EOutArgsDfDp_mp

enum  EOutArgs_g_mp

enum  EOutArgsDgDx_dot_mp

enum  EOutArgsDgDx_mp

enum  EOutArgsDgDp_mp

typedef Teuchos::ScalarTraits
< Scalar >::magnitudeType
ScalarMag

- Static Public Attributes inherited from Thyra::ModelEvaluator< class >
static const int NUM_E_IN_ARGS_MEMBERS

static const int NUM_E_OUT_ARGS_MEMBERS

- Static Public Attributes inherited from Teuchos::Describable
static const EVerbosityLevel verbLevel_default

- Protected Member Functions inherited from Teuchos::ParameterListAcceptorDefaultBase
void setMyParamList (const RCP< ParameterList > &paramList)

RCP< ParameterListgetMyNonconstParamList ()

RCP< const ParameterListgetMyParamList () const


Detailed Description

template<class Scalar>
class Tempus_Test::VanDerPolModel< Scalar >

van der Pol model problem for nonlinear electrical circuit.

This is a canonical equation of a nonlinear oscillator (Hairer, Norsett, and Wanner, pp. 111-115, and Hairer and Wanner, pp. 4-5) for an electrical circuit. In implicit ODE form, $ \mathcal{F}(\dot{x},x,t) = 0 $, the scaled problem can be written as

\begin{eqnarray*} \mathcal{F}_0 & = & \dot{x}_0(t) - x_1(t) = 0 \\ \mathcal{F}_1 & = & \dot{x}_1(t) - [(1-x_0^2)x_1-x_0]/\epsilon = 0 \end{eqnarray*}

where the initial conditions are

\begin{eqnarray*} x_0(t_0=0) & = & 2 \\ x_1(t_0=0) & = & 0 \end{eqnarray*}

and the initial time derivatives are

\begin{eqnarray*} \dot{x}_0(t_0=0) & = & x_1(t_0=0) = 0 \\ \dot{x}_1(t_0=0) & = & [(1-x_0^2)x_1-x_0]/\epsilon = -2/\epsilon \end{eqnarray*}

Hairer and Wanner suggest the output times of $t = 1,2,3,4,...,11$, and $\epsilon = 10^{-6}$ to make the problem very stiff. For $\epsilon = 0$, the solution becomes

\begin{eqnarray*} \ln \left|x_0\right| - \frac{x_0^2}{2} & = & t + C \\ x_1 & = & \frac{x_0}{1-x_0^2} \end{eqnarray*}

where $C =\ln \left|x_0(t=0)\right| - \frac{x_0^2(t=0)}{2} =-1.306853.$

The components of iteration matrix, $W$, are defined to be

\[ W_{ij} \equiv \frac{d\mathcal{F}_i}{dx_j} = \frac{d}{dx_j} \mathcal{F}_i (\dot{x}_i, x_0, \ldots, x_k, \ldots, x_K, t) \]

(not using Einstein summation). Using the chain rule, we can write

\[ \frac{d\mathcal{F}_i}{dx_j} = \frac{\partial\dot{x}_i}{\partial x_j} \frac{\partial\mathcal{F}_i}{\partial \dot{x}_i} + \sum_{k=0}^K \frac{\partial x_k}{\partial x_j} \frac{\partial\mathcal{F}_i}{\partial x_k} + \frac{\partial t}{\partial x_j} \frac{\partial\mathcal{F}_i}{\partial t} \]

but noting that $\partial t/\partial x_j = 0$ and

\[ \frac{\partial x_k}{\partial x_j} = \left\{ \begin{array}{c} 1 \mbox{ if } j = k \\ 0 \mbox{ if } j \neq k \end{array} \right. \]

we can write

\[ \frac{d\mathcal{F}_i}{dx_j} = \alpha \frac{\partial\mathcal{F}_i}{\partial \dot{x}_j} + \beta \frac{\partial\mathcal{F}_i}{\partial x_j} \]

where

\[ \alpha = \left\{ \begin{array}{cl} \frac{\partial\dot{x}_i}{\partial x_j} & \mbox{ if } i = j \\ 0 & \mbox{ if } i \neq j \end{array} \right. \;\;\;\; \mbox{ and } \;\;\;\; \beta = \left\{ \begin{array}{cl} \frac{\partial x_k}{\partial x_j} = 1 & \mbox{ if } j = k \\ 0 & \mbox{ if } j \neq k \end{array} \right. \]

Thus for the van der Pol problem, we have

\begin{eqnarray*} W_{00} = \alpha \frac{\partial\mathcal{F}_0}{\partial \dot{x}_0} + \beta \frac{\partial\mathcal{F}_0}{\partial x_0} & = & \alpha \\ W_{01} = \alpha \frac{\partial\mathcal{F}_0}{\partial \dot{x}_1} + \beta \frac{\partial\mathcal{F}_0}{\partial x_1} & = & -\beta \\ W_{10} = \alpha \frac{\partial\mathcal{F}_1}{\partial \dot{x}_0} + \beta \frac{\partial\mathcal{F}_1}{\partial x_0} & = & \beta (2 x_0 x_1 + 1)/\epsilon \\ W_{11} = \alpha \frac{\partial\mathcal{F}_1}{\partial \dot{x}_1} + \beta \frac{\partial\mathcal{F}_1}{\partial x_1} & = & \alpha + \beta (x^2_0 - 1)/\epsilon \\ \end{eqnarray*}

Definition at line 111 of file VanDerPolModel_decl.hpp.

Constructor & Destructor Documentation

template<class Scalar >
Tempus_Test::VanDerPolModel< Scalar >::VanDerPolModel ( Teuchos::RCP< Teuchos::ParameterList pList = Teuchos::null)

Definition at line 29 of file VanDerPolModel_impl.hpp.

Member Function Documentation

template<class Scalar >
Thyra::ModelEvaluatorBase::InArgs< Scalar > Tempus_Test::VanDerPolModel< Scalar >::getExactSolution ( double  t) const

Definition at line 57 of file VanDerPolModel_impl.hpp.

template<class Scalar >
Thyra::ModelEvaluatorBase::InArgs< Scalar > Tempus_Test::VanDerPolModel< Scalar >::getExactSensSolution ( int  j,
double  t
) const

Definition at line 67 of file VanDerPolModel_impl.hpp.

template<class Scalar >
Teuchos::RCP< const Thyra::VectorSpaceBase< Scalar > > Tempus_Test::VanDerPolModel< Scalar >::get_x_space ( ) const
virtual

Implements Thyra::ModelEvaluator< class >.

Definition at line 77 of file VanDerPolModel_impl.hpp.

template<class Scalar >
Teuchos::RCP< const Thyra::VectorSpaceBase< Scalar > > Tempus_Test::VanDerPolModel< Scalar >::get_f_space ( ) const
virtual

Implements Thyra::ModelEvaluator< class >.

Definition at line 86 of file VanDerPolModel_impl.hpp.

template<class Scalar >
Thyra::ModelEvaluatorBase::InArgs< Scalar > Tempus_Test::VanDerPolModel< Scalar >::getNominalValues ( ) const
virtual

Implements Thyra::ModelEvaluator< class >.

Definition at line 95 of file VanDerPolModel_impl.hpp.

template<class Scalar >
Teuchos::RCP< Thyra::LinearOpWithSolveBase< Scalar > > Tempus_Test::VanDerPolModel< Scalar >::create_W ( ) const
virtual

Implements Thyra::ModelEvaluator< class >.

Definition at line 106 of file VanDerPolModel_impl.hpp.

template<class Scalar >
Teuchos::RCP< Thyra::LinearOpBase< Scalar > > Tempus_Test::VanDerPolModel< Scalar >::create_W_op ( ) const
virtual

Implements Thyra::ModelEvaluator< class >.

Definition at line 144 of file VanDerPolModel_impl.hpp.

template<class Scalar >
Teuchos::RCP< const Thyra::LinearOpWithSolveFactoryBase< Scalar > > Tempus_Test::VanDerPolModel< Scalar >::get_W_factory ( ) const
virtual

Implements Thyra::ModelEvaluator< class >.

Definition at line 154 of file VanDerPolModel_impl.hpp.

template<class Scalar >
Thyra::ModelEvaluatorBase::InArgs< Scalar > Tempus_Test::VanDerPolModel< Scalar >::createInArgs ( ) const
virtual

Implements Thyra::ModelEvaluator< class >.

Definition at line 165 of file VanDerPolModel_impl.hpp.

template<class Scalar >
Teuchos::RCP< const Thyra::VectorSpaceBase< Scalar > > Tempus_Test::VanDerPolModel< Scalar >::get_p_space ( int  l) const
virtual

Implements Thyra::ModelEvaluator< class >.

Definition at line 286 of file VanDerPolModel_impl.hpp.

template<class Scalar >
Teuchos::RCP< const Teuchos::Array< std::string > > Tempus_Test::VanDerPolModel< Scalar >::get_p_names ( int  l) const
virtual

Implements Thyra::ModelEvaluator< class >.

Definition at line 298 of file VanDerPolModel_impl.hpp.

template<class Scalar >
Teuchos::RCP< const Thyra::VectorSpaceBase< Scalar > > Tempus_Test::VanDerPolModel< Scalar >::get_g_space ( int  j) const
virtual

Implements Thyra::ModelEvaluator< class >.

Definition at line 313 of file VanDerPolModel_impl.hpp.

template<class Scalar >
void Tempus_Test::VanDerPolModel< Scalar >::setParameterList ( Teuchos::RCP< Teuchos::ParameterList > const &  paramList)
virtual

Implements Teuchos::ParameterListAcceptor.

Definition at line 396 of file VanDerPolModel_impl.hpp.

template<class Scalar >
Teuchos::RCP< const Teuchos::ParameterList > Tempus_Test::VanDerPolModel< Scalar >::getValidParameters ( ) const
virtual

Reimplemented from Teuchos::ParameterListAcceptor.

Definition at line 424 of file VanDerPolModel_impl.hpp.

template<class Scalar >
void Tempus_Test::VanDerPolModel< Scalar >::setupInOutArgs_ ( ) const
private

Definition at line 324 of file VanDerPolModel_impl.hpp.

template<class Scalar >
Thyra::ModelEvaluatorBase::OutArgs< Scalar > Tempus_Test::VanDerPolModel< Scalar >::createOutArgsImpl ( ) const
private

Definition at line 178 of file VanDerPolModel_impl.hpp.

template<class Scalar >
void Tempus_Test::VanDerPolModel< Scalar >::evalModelImpl ( const Thyra::ModelEvaluatorBase::InArgs< Scalar > &  inArgs_bar,
const Thyra::ModelEvaluatorBase::OutArgs< Scalar > &  outArgs_bar
) const
private

Definition at line 188 of file VanDerPolModel_impl.hpp.

Member Data Documentation

template<class Scalar >
int Tempus_Test::VanDerPolModel< Scalar >::dim_
private

Number of state unknowns (2)

Definition at line 162 of file VanDerPolModel_decl.hpp.

template<class Scalar >
int Tempus_Test::VanDerPolModel< Scalar >::Np_
private

Number of parameter vectors (1)

Definition at line 163 of file VanDerPolModel_decl.hpp.

template<class Scalar >
int Tempus_Test::VanDerPolModel< Scalar >::np_
private

Number of parameters in this vector (1)

Definition at line 164 of file VanDerPolModel_decl.hpp.

template<class Scalar >
int Tempus_Test::VanDerPolModel< Scalar >::Ng_
private

Number of observation functions (0)

Definition at line 165 of file VanDerPolModel_decl.hpp.

template<class Scalar >
int Tempus_Test::VanDerPolModel< Scalar >::ng_
private

Number of elements in this observation function (0)

Definition at line 166 of file VanDerPolModel_decl.hpp.

template<class Scalar >
bool Tempus_Test::VanDerPolModel< Scalar >::haveIC_
private

false => no nominal values are provided (default=true)

Definition at line 167 of file VanDerPolModel_decl.hpp.

template<class Scalar >
bool Tempus_Test::VanDerPolModel< Scalar >::acceptModelParams_
private

Changes inArgs to require parameters.

Definition at line 168 of file VanDerPolModel_decl.hpp.

template<class Scalar >
bool Tempus_Test::VanDerPolModel< Scalar >::isInitialized_
mutableprivate

Definition at line 169 of file VanDerPolModel_decl.hpp.

template<class Scalar >
Thyra::ModelEvaluatorBase::InArgs<Scalar> Tempus_Test::VanDerPolModel< Scalar >::inArgs_
mutableprivate

Definition at line 170 of file VanDerPolModel_decl.hpp.

template<class Scalar >
Thyra::ModelEvaluatorBase::OutArgs<Scalar> Tempus_Test::VanDerPolModel< Scalar >::outArgs_
mutableprivate

Definition at line 171 of file VanDerPolModel_decl.hpp.

template<class Scalar >
Thyra::ModelEvaluatorBase::InArgs<Scalar> Tempus_Test::VanDerPolModel< Scalar >::nominalValues_
mutableprivate

Definition at line 172 of file VanDerPolModel_decl.hpp.

template<class Scalar >
Teuchos::RCP<const Thyra::VectorSpaceBase<Scalar> > Tempus_Test::VanDerPolModel< Scalar >::x_space_
private

Definition at line 173 of file VanDerPolModel_decl.hpp.

template<class Scalar >
Teuchos::RCP<const Thyra::VectorSpaceBase<Scalar> > Tempus_Test::VanDerPolModel< Scalar >::f_space_
private

Definition at line 174 of file VanDerPolModel_decl.hpp.

template<class Scalar >
Teuchos::RCP<const Thyra::VectorSpaceBase<Scalar> > Tempus_Test::VanDerPolModel< Scalar >::p_space_
private

Definition at line 175 of file VanDerPolModel_decl.hpp.

template<class Scalar >
Teuchos::RCP<const Thyra::VectorSpaceBase<Scalar> > Tempus_Test::VanDerPolModel< Scalar >::g_space_
private

Definition at line 176 of file VanDerPolModel_decl.hpp.

template<class Scalar >
Scalar Tempus_Test::VanDerPolModel< Scalar >::epsilon_
private

This is a model parameter.

Definition at line 179 of file VanDerPolModel_decl.hpp.

template<class Scalar >
Scalar Tempus_Test::VanDerPolModel< Scalar >::t0_ic_
private

initial time

Definition at line 180 of file VanDerPolModel_decl.hpp.

template<class Scalar >
Scalar Tempus_Test::VanDerPolModel< Scalar >::x0_ic_
private

initial condition for x0

Definition at line 181 of file VanDerPolModel_decl.hpp.

template<class Scalar >
Scalar Tempus_Test::VanDerPolModel< Scalar >::x1_ic_
private

initial condition for x1

Definition at line 182 of file VanDerPolModel_decl.hpp.


The documentation for this class was generated from the following files:
